Topsky Energy JAM72D40-600/LB
PayPal Pay in 4 interest-free payments of $52.50 on qualifying orders, or monthly financing with PayPal Pay Later.
Available at checkout for eligible US buyers. Subject to approval.
Ships by freight. Carrier checkout rates can’t price this correctly — we quote the exact delivered rate to your ZIP.
Orders ship via freight or ground from our Louisville, KY warehouse. Tracking provided once your order ships.
Ships via LTL freight — palletized, liftgate available. Our team confirms freight details within 1 business day.
Secure checkout · Wire/ACH accepted on quotes · Freight arranged for you
Transit estimates from Louisville, KY. Freight details →
- SKU
- PES-SPS-SOL-21216
Complete the job
Compatible gear contractors pair with this item
PES Supply is an authorized distributor for JA Solar. 50,000+ SKUs from 169 authorized brands.
Type Monocrystalline Model No. JAM72D40-600/LB Product Warranty 12 Years Power Warranty 1 Years of 99 %, 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 600 Wp Voltage at Maximum Power (Vmpp) 43.76 V Current at Maximum Power (Impp) 13.71 A Open Circuit Voltage (Voc) 52.4 V Short Circuit Current (Isc) 14.48 A Panel Efficiency 22.7 % Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 2333x1134x30 mm Weight 32.5 kg Cell Number 144 Glass Thickness 2 mm Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Download Manufacturer's PDF Datasheet
Technology: Bifacial, N-type
Power Range: 590 ~ 610 Wp
Panel Efficiency: 22.3 ~ 23.1 %
Weight: 32.5 kg
Seller Name: Shenzhen Topsky Energy Co., Ltd.
Country: China
| SKU | PES-SPS-SOL-21216 |
|---|---|
| Manufacturer | JA Solar |
| Brand | |
| Container price | |
| Container qty | |
| Odoo id | |
| Pallet price | |
| Pallet qty | |
| Unit price | |
| Manufacturer | |
| Model number |
No documents available for this product. Contact us to request documentation.
