    Topsky Energy LR5-54HTDB-425M

    Topsky Energy LR5-54HTDB-425M

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-21228
    • Brand: LONGi
    • Container price: $48.60 USD
    • Container qty: 720
    • Odoo id: 25,498
    • Pallet price: $2.29 USD
    • Pallet qty: 30
    View full details

    Product Description

    • Type Monocrystalline Model No. LR5-54HTDB-425M Product Warranty 25 Years Power Warranty 1 Years of 98.5 %, 30 Years of 86.9 % Total Degradation Rate ⏳ 0.44 % Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 425 Wp Voltage at Maximum Power (Vmpp) 33.27 V Current at Maximum Power (Impp) 12.78 A Open Circuit Voltage (Voc) 39.65 V Short Circuit Current (Isc) 13.61 A Panel Efficiency 21.8 % Maximum Power (Pmax) 317.6 Wp Voltage at Maximum Power (Vmpp) 30.36 V Current at Maximum Power (Impp) 10.46 A Open Circuit Voltage (Voc) 37.23 V Short Circuit Current (Isc) 10.99 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.23 %/°C Temperature Coefficient of Isc 0.05 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 1722x1134x30 mm Weight 22.5 kg Cell Number 108 Glass Thickness 2 mm Frame Type Anodized Aluminium, Black Junction Box Protection Class IP 68 Cable Crossection 4 mm2 Cab

      Power Range: 425 ~ 430 Wp
      Panel Efficiency: 21.8 ~ 22 %
      Weight: 22.5 kg
      Seller Name: Shenzhen Topsky Energy Co., Ltd.
      Country: China
