TSEC TS54-CMH-440 H1 TOPCon Monocrystalline Solar Panel
TSEC TS54-CMH-440 H1 TOPCon Monocrystalline Solar Panel
TS54-CMH-440 H1 | TOPCon | 108 Monocrystalline Cells | Mono-Facial | 1500V System Voltage
Product Overview
The TSEC TS54-CMH-440 H1 TOPCon Monocrystalline Solar Panel delivers exceptional performance for modern energy systems. This advanced module features 108 high-efficiency TOPCon cells designed for maximum power output. It achieves an impressive 22.5% module efficiency under standard test conditions. The panel generates 440 Wp of power, making it ideal for residential and commercial applications. Its robust construction ensures durability against harsh environmental conditions like salt mist and mechanical loads. The black frame design enhances aesthetic appeal for any installation site. Made in Taiwan, this product reflects TSEC's commitment to quality and sustainable development. It offers superior low-light response and better temperature coefficients than traditional panels. The 1500V maximum system voltage supports flexible grid configurations. This solar panel is a top choice for professionals seeking reliable green energy solutions.
Key Benefits
High Power Output: Generates 440 Wp for efficient energy production in limited spaces.
Advanced TOPCon Technology: Uses tunnel oxide passivated contact cells for reduced degradation and higher efficiency.
Superior Durability: Features an anti-salt mist frame and withstands 5400 Pa mechanical load tests.
Excellent Temperature Performance: Better temperature coefficient ensures stable output even in hot climates.
Long Warranty Period: Includes a 12-year material warranty and 30-year linear power warranty.
How It Works
This TOPCon solar panel converts sunlight into electricity using advanced semiconductor physics. The 108 monocrystalline cells absorb photons and release electrons to generate current. The tunnel oxide layer minimizes electron recombination for higher efficiency. This design reduces light-induced degradation significantly over time. The module operates efficiently even under low-light conditions like dawn or dusk. It maintains power output better than standard panels when temperatures rise. The junction box manages the electrical flow safely to the grid connection.
Photon Absorption: Sunlight hits the 182mm solar cells, releasing electrons to create an electrical current. This process starts the energy conversion cycle immediately upon exposure.
Passivation Layer: The tunnel oxide passivated contact layer prevents electron loss at the cell surface. This technology boosts overall module efficiency beyond standard monocrystalline limits.
Current Collection: Generated electricity flows through the busbars to the junction box. The IP68 rated box ensures safe transmission to external inverters.
Technical Specifications
| Model Number | TS54-CMH-440 H1 |
| Technology Type | TOPCon Monocrystalline |
| Max Power (Pmax) | 440 Wp |
| Module Efficiency | 22.5% |
| Cell Count | 108 (6x18) |
| Voltage at Pmax (Vmpp) | 33.52 V |
| Current at Pmax (Impp) | 13.14 A |
| Open Circuit Voltage (Voc) | 39.44 V |
| Short Circuit Current (Isc) | 13.75 A |
| Power Tolerance | -3% to +3% |
| Dimensions (H/W/D) | 1723 x 1134 x 35 mm |
| Weight | 21.5 kg |
| Frame Type | Black Anti-Salt Mist |
| Junction Box Rating | IP68 (3 Diodes) |
| Max System Voltage | 1500 V DC |
| Operating Temp Range | -40°C to +85°C |
| Temp Coeff of Pmax | -0.29%/°C |
| Cable Length | 1500 mm (4mm²) |
| Series Fuse Rating | 25 A |
| Degradation Rate (30Y) | 87.4% |
Certifications & Compliance
Certifications: IEC 61215:2021, IEC 61730-1:2021, IEC 61730-2:2021, UL 61730
Inverter Compatibility: Compatible with major inverters supporting 1500V systems
Environmental: ISO 14001:2015, Zero Light-Induced Degradation, Salt Mist Tested
Warranty: 12-year material and workmanship warranty, 30-year linear power warranty
