TSEC TS54-CMH-450 H1 TOPCon Monocrystalline Solar Panel
TS54-CMH-450 H1 | TOPCon | 108 Mono-Crystalline Cells | Mono | 1500V System Voltage
Product Overview
The TSEC TS54-CMH-450 H1 TOPCon Monocrystalline Solar Panel delivers exceptional 450 Wp power output with 23% efficiency. This advanced module features 108 high-performance TOPCon cells designed for maximum energy generation. Its robust construction ensures reliable performance in diverse weather conditions. The panel supports a maximum system voltage of 1500V, ideal for large-scale commercial installations. Manufactured in Taiwan, this green energy solution combines cutting-edge technology with sustainable practices. It offers superior low-light response and better temperature coefficients than standard panels. The anti-salt mist frame protects against harsh coastal environments. With a 12-year material warranty and 30-year linear power warranty, this panel guarantees long-term value. Its compact 1723x1134x35 mm dimensions fit various mounting configurations easily. The black frame design enhances aesthetic appeal for residential projects.
Key Benefits
High Efficiency Output: Achieves 23% module efficiency for maximum energy generation per square meter.
Advanced TOPCon Technology: Utilizes 108 TOPCon cells with zero light-induced degradation for stable performance.
Superior Temperature Coefficient: Features -0.29%/°C Pmax coefficient for better output in hot climates.
Extreme Durability: Passes toughest salt mist and 5400 Pa mechanical load tests for harsh environments.
Long-Term Warranty: Includes 12-year material warranty and 30-year linear power warranty for peace of mind.
How It Works
This solar panel converts sunlight into electricity using 108 high-efficiency TOPCon monocrystalline silicon cells. The tunnel oxide passivated contact technology reduces electron recombination for higher current output. Advanced encapsulation materials protect cells while allowing maximum light transmission. The anti-salt mist frame ensures structural integrity against corrosive coastal winds. An IP68-rated junction box safely houses three bypass diodes for system protection. The panel operates efficiently between -40°C and +85°C ambient temperatures. Low water vapor transmission film prevents internal moisture damage over decades. This design ensures consistent power generation even under low-light morning or evening conditions.
Photon Absorption: TOPCon cells absorb sunlight photons to generate electron flow efficiently. The oxide layer minimizes energy loss during this conversion process.
Current Collection: Generated electrons flow through conductive pathways to the junction box. Bypass diodes prevent power loss if part of the panel is shaded.
System Integration: The 1500V maximum system voltage enables series connections for large arrays. The 25A fuse rating protects against electrical overloads safely.
Technical Specifications
| Cell Type | Monocrystalline TOPCon |
| Cells per Module | 108 pcs |
| Max Power (Pmax) | 450 Wp |
| Module Efficiency | 23% |
| Voltage at Max Power (Vmpp) | 33.89 V |
| Current at Max Power (Impp) | 13.3 A |
| Open Circuit Voltage (Voc) | 39.82 V |
| Short Circuit Current (Isc) | 13.93 A |
| Power Tolerance | -3% to +3% |
| Temperature Coefficient Pmax | -0.29%/°C |
| Temperature Coefficient Voc | -0.25%/°C |
| Temperature Coefficient Isc | +0.045%/°C |
| Nominal Operating Cell Temp | 45±2 °C |
| Operating Temperature Range | -40°C to +85°C |
| Max System Voltage | 1500 V |
| Series Fuse Rating | 25 A |
| Dimensions (H/W/D) | 1723 x 1134 x 35 mm |
| Weight | 21.5 kg |
| Frame Type | Black Anti-Salt Mist |
| Junction Box Protection | IP68 |
| Bypass Diodes | 3 |
| Cable Cross-Section | 4 mm² |
| Cable Length | 1500 mm |
| Max Mechanical Load | 5400 Pa |
| Fire Resistance Class | Class C |
| Protection Class | Class II |
Certifications & Compliance
Certifications: IEC 61215:2021, IEC 61730-1:2021, IEC 61730-2:2021, UL 61730
Inverter Compatibility: Compatible with all standard PV inverters supporting 1500V systems
Environmental: ISO 9001:2015 Quality, ISO 14001:2015 Environmental, ISO 45001:2018 Safety
Warranty: 12-year materials and workmanship warranty; 30-year linear power warranty (91.4% at 30 years)
