TSEC TS60-CMH-475 H1 TOPCon Monocrystalline Solar Panel
TS60-CMH-475 H1 | TOPCon | 120 Half-Cell | Monocrystalline | 1500V System Voltage
Product Overview
The TSEC TS60-CMH-475 H1 TOPCon Monocrystalline Solar Panel delivers exceptional performance for modern energy systems. This advanced panel features 120 high-efficiency TOPCon cells within a robust 1908x1134x35 mm frame. It generates 475 Wp of power with a 22.0% module conversion efficiency. The panel is built to withstand harsh conditions, including extreme salt mist and high mechanical loads. Its superior temperature coefficient ensures better output in hot climates compared to standard panels. Manufactured in Taiwan, this green energy solution supports sustainable development goals. The design includes an IP68 junction box for ultimate protection against dust and water. It offers a 30-year linear power warranty with 87.4% output retention. This makes it ideal for residential, commercial, and industrial solar installations worldwide.
Key Benefits
High Efficiency Output: Achieves 22.0% conversion efficiency with 475 Wp power for maximum energy generation.
TOPCon Technology: Uses advanced Tunnel Oxide Passivated Contact cells to reduce light-induced degradation and improve low-light response.
Superior Temperature Performance: Features a -0.29%/°C Pmax coefficient for better efficiency in high-temperature environments.
Extreme Durability: Passes the toughest salt mist tests and supports 5400 Pa mechanical load for long-term reliability.
Long Warranty Coverage: Includes a 12-year material warranty and a 30-year linear power warranty guaranteeing 87.4% output.
How It Works
This solar panel converts sunlight into electricity using 120 monocrystalline TOPCon cells. Each cell captures photons to generate a flow of electrons through the semiconductor material. The passivated contact layer minimizes electron loss, boosting overall efficiency significantly. The anti-salt mist frame protects the internal components from corrosive environmental elements. The IP68 junction box safely channels the generated current to your system without leakage. This process ensures consistent power output even under challenging weather conditions. The design supports a maximum system voltage of 1500 V for efficient grid integration.
Photon Absorption: Sunlight hits the 182mm solar cells, exciting electrons to create an electrical current. This process starts the energy conversion immediately upon exposure to light.
Passivation Layer: The Tunnel Oxide layer reduces recombination losses at the cell surface. This ensures more electrons reach the circuit for higher power output.
Current Collection: The 3 bypass diodes and IP68 junction box manage the current flow safely. This prevents power loss during partial shading or component failure.
Technical Specifications
| Max Power (Pmax) | 475 Wp |
| Module Efficiency | 22.0% |
| Cell Type | Monocrystalline TOPCon |
| Cell Count | 120 Cells |
| Voltage at Max Power (Vmpp) | 36.12 V |
| Current at Max Power (Impp) | 13.16 A |
| Open Circuit Voltage (Voc) | 42.54 V |
| Short Circuit Current (Isc) | 13.83 A |
| Power Tolerance | -3% to +3% |
| Temperature Coefficient (Pmax) | -0.29%/°C |
| Nominal Operating Cell Temp | 45±2 °C |
| Operating Temperature Range | -40 to +85 °C |
| Max System Voltage | 1500 V |
| Series Fuse Rating | 25 A |
| Dimensions (H/W/D) | 1908 x 1134 x 35 mm |
| Weight | 23.5 kg |
| Junction Box Protection | IP68 |
| Cable Length | 1500 mm |
| Cable Cross-section | 4 mm² |
| Frame Color | Black |
| Degradation Rate (Year 1) | 0.42% |
Certifications & Compliance
Certifications: IEC 61215:2021, IEC 61730-1:2021, IEC 61730-2:2021, UL 61730
Inverter Compatibility: Compatible with EVO-2 connectors and standard grid-tie inverters
Environmental: ISO 9001:2015 Quality, ISO 14001:2015 Environmental, ISO 45001:2018 Safety
Warranty: 12-year material and workmanship warranty; 30-year linear power warranty (87.4% at year 30)
