Ulica Solar UL-435M-108ADGN
PayPal Pay in 4 interest-free payments of $38.00 on qualifying orders, or monthly financing with PayPal Pay Later.
Available at checkout for eligible US buyers. Subject to approval.
Ships by freight. Carrier checkout rates can’t price this correctly — we quote the exact delivered rate to your ZIP.
Orders ship via freight or ground from our Louisville, KY warehouse. Tracking provided once your order ships.
Ships via LTL freight — palletized, liftgate available. Our team confirms freight details within 1 business day.
Secure checkout · Wire/ACH accepted on quotes · Freight arranged for you
Transit estimates from Louisville, KY. Freight details →
- SKU
- PES-SPS-SOL-21863
Complete the job
Compatible gear contractors pair with this item
PES Supply is an authorized distributor for PES Global. 50,000+ SKUs from 169 authorized brands.
Type Monocrystalline Model No. UL-435M-108ADGN Product Warranty 15 Years Power Warranty 15 Years of 90 %, 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 435 Wp Voltage at Maximum Power (Vmpp) 31.91 V Current at Maximum Power (Impp) 13.63 A Open Circuit Voltage (Voc) 39.39 V Short Circuit Current (Isc) 13.95 A Panel Efficiency 22.28 % Maximum Power (Pmax) 330 Wp Voltage at Maximum Power (Vmpp) 29.36 V Current at Maximum Power (Impp) 11.13 A Open Circuit Voltage (Voc) 35.84 V Short Circuit Current (Isc) 11.2 A Temperature 43±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.046 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 1722x1134x30 mm Weight 23.5 kg Cell Size 182×91 mm Cell Number 108 Glass Type Anti-reflection Coating, Tempered Glass Thickness 2 mm Frame Type Anodized Aluminium, Black
Technology: Bifacial, TOPCon
Power Range: 435 ~ 445 Wp
Panel Efficiency: 22.28 ~ 22.79 %
Weight: 23.5 kg
Seller Name: Ningbo Ulica Solar Co., Ltd.
Country: China
| SKU | PES-SPS-SOL-21863 |
|---|---|
| Manufacturer | PES Global |
| Container price | |
| Container qty | |
| Odoo id | |
| Pallet price | |
| Pallet qty | |
| Unit price | |
| Manufacturer | |
| Model number |
No documents available for this product. Contact us to request documentation.
