    Ulica Solar UL-550M-144HV

    Ulica Solar UL-550M-144HV

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-21877
    • Container price: $54.00 USD
    • Container qty: 720
    • Odoo id: 24,892
    • Pallet price: $2.55 USD
    • Pallet qty: 30
    • Unit price: $0.10 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. UL-550M-144HV Product Warranty 12 Years Power Warranty 10 Years of 93.05 %, 25 Years of 84.8 % Total Degradation Rate ⏳ 0.61 % Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 550 Wp Voltage at Maximum Power (Vmpp) 41.9 V Current at Maximum Power (Impp) 13.13 A Open Circuit Voltage (Voc) 50 V Short Circuit Current (Isc) 13.75 A Panel Efficiency 21.28 % Temperature 43±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.36 %/°C Temperature Coefficient of Voc -0.29 %/°C Temperature Coefficient of Isc 0.049 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2279x1134x35 mm Weight 27.5 kg Cell Size 182×91 mm Cell Number 144 Glass Type Tempered Glass Thickness 3.2 mm Encapsulant Type EVA Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 1400 mm Download Manufacturer's PDF Datasheet

      Power Range: 545 ~ 555 Wp
      Panel Efficiency: 21.09 ~ 21.48 %
      Weight: 27.5 kg
      Seller Name: Ningbo Ulica Solar Co., Ltd.
      Country: China
