Ulica Solar UL-610M-156ADGN
Ulica Solar UL-610M-156ADGN
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-21880
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. UL-610M-156ADGN Product Warranty 15 Years Power Warranty 15 Years of 90 %, 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 610 Wp Voltage at Maximum Power (Vmpp) 48.26 V Current at Maximum Power (Impp) 12.63 A Open Circuit Voltage (Voc) 57.08 V Short Circuit Current (Isc) 13.32 A Panel Efficiency 22.58 % Maximum Power (Pmax) 462 Wp Voltage at Maximum Power (Vmpp) 44.42 V Current at Maximum Power (Impp) 10.41 A Open Circuit Voltage (Voc) 51.94 V Short Circuit Current (Isc) 10.74 A Temperature 43±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.046 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 2382x1134x30 mm Weight 32 kg Cell Size 182.2×88 mm Cell Number 156 Glass Type Anti-reflection Coating, Tempered Glass Thickness 2 mm Encapsulant Type EVA Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 1400 mm Download Manufacturer's PDF Datasheet
Technology: Bifacial, N-type
Power Range: 605 ~ 615 Wp
Panel Efficiency: 22.4 ~ 22.75 %
Weight: 32 kg
Seller: Ningbo Ulica Solar Co., Ltd.
Country: China -
