Ulica Solar UL-615M-156ADGN
PayPal Pay in 4 interest-free payments of $53.75 on qualifying orders, or monthly financing with PayPal Pay Later.
Available at checkout for eligible US buyers. Subject to approval.
Ships by freight. Carrier checkout rates can’t price this correctly — we quote the exact delivered rate to your ZIP.
Orders ship via freight or ground from our Louisville, KY warehouse. Tracking provided once your order ships.
Ships via LTL freight — palletized, liftgate available. Our team confirms freight details within 1 business day.
Secure checkout · Wire/ACH accepted on quotes · Freight arranged for you
Transit estimates from Louisville, KY. Freight details →
- SKU
- PES-SPS-SOL-21881
Complete the job
Compatible gear contractors pair with this item
PES Supply is an authorized distributor for ENF Solar. 50,000+ SKUs from 169 authorized brands.
Type Monocrystalline Model No. UL-615M-156ADGN Product Warranty 15 Years Power Warranty 15 Years of 90 %, 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 615 Wp Voltage at Maximum Power (Vmpp) 48.4 V Current at Maximum Power (Impp) 12.71 A Open Circuit Voltage (Voc) 57.21 V Short Circuit Current (Isc) 13.36 A Panel Efficiency 22.75 % Maximum Power (Pmax) 466 Wp Voltage at Maximum Power (Vmpp) 44.53 V Current at Maximum Power (Impp) 10.47 A Open Circuit Voltage (Voc) 52.06 V Short Circuit Current (Isc) 10.78 A Temperature 43±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.046 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 2382x1134x30 mm Weight 32 kg Cell Size 182.2×88 mm Cell Number 156 Glass Type Anti-reflection Coating, Tempered Glass Thickness 2 mm Encapsulant Type EVA Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 1400 mm Download Manufacturer's PDF Datasheet
Technology: Bifacial, N-type
Power Range: 605 ~ 615 Wp
Panel Efficiency: 22.4 ~ 22.75 %
Weight: 32 kg
Seller: Ningbo Ulica Solar Co., Ltd.
Country: China
| SKU | PES-SPS-SOL-21881 |
|---|---|
| Manufacturer | ENF Solar |
| Container price | |
| Container qty | |
| Pallet price | |
| Pallet qty | |
| Unit price | |
| Manufacturer | |
| Model number |
No documents available for this product. Contact us to request documentation.
