The Victron Orion-Tr 48/24-5A (120W) is an advanced isolated DC-DC converter designed to provide efficient power conversion for various applications. Specifically engineered by Victron Energy, this model serves as a reliable solution for converting 48V to 24V, ensuring stable performance while safeguarding your devices. With features like remote on-off capability and high-temperature protection, users can enjoy peace of mind knowing their power needs are met efficiently and safely.
The remote on-off feature simplifies control by eliminating the need for a high-current switch in the wiring. This can be activated via a low-power switch or any standard engine run/stop switch, making it user-friendly and versatile while implementing the Victron Energy ORI482410110.
All Victron Orion-Tr models, including the ORI482410110, are equipped with short circuit protection. This safety feature ensures that the converter will not be disabled during short circuit conditions, thus providing enhanced reliability during operation.
The Orion-Tr 48/24-5A includes built-in high-temperature protection that automatically reduces the output current under high ambient temperature conditions. This helps prevent overheating and ensures long-lasting performance, crucial for safeguarding valuable electronics.
With the ability to connect an unlimited number of units in parallel, users can easily increase the output current when needed. This feature enhances the versatility of the Victron Energy ORI482410110 converter, allowing for scalable power solutions to meet diverse needs.
The output voltage of the Orion-Tr 48/24-5A can be adjusted within a specific range. However, it should be noted that it is not intended for battery charging. For battery charging applications, consider utilizing an Orion-Tr Smart for optimized performance.
The Victron Orion-Tr 48/24-5A operates by converting input voltage from a higher DC voltage to a lower DC voltage. The conversion process maintains consistent output voltage under specified conditions, making it ideal for various applications such as powering 24V systems from a 48V supply.
This DC-DC converter connects through standard screw terminals, allowing for straightforward installation without the need for specialized tools. This design is user-friendly and aids in quick setup for all users.
The output from this converter features a nominal voltage of 24.2 V, ensuring that connected devices receive reliable power. The performance is retained within specified tolerances at varying loads.
With galvanic isolation rated at 200V DC between the input and output, this converter adheres to stringent safety standards, making it a trustworthy choice for sensitive applications. It meets various safety and emission standards, ensuring compliance in diverse environments.
| Model | Victron Orion-Tr 48/24-5A |
| Input Voltage Range | 40-70 V DC |
| Output Voltage | 24.2 V |
| Continuous Output Current | 5 A |
| Input Fuse | Not replaceable |
| Efficiency | 88% |
| Operating Temperature Range | -20 to +55 °C |
| Dimensions (HxWxD) | 130 x 186 x 70 mm |
| Weight | 1.3 kg (3 lb) |
| Protection Class | IP43 when screw terminals oriented downwards |
| Warranty | 5 years |
