• SMA Sunny Tripower Core1 62-US 480V 62.5KW 120A String Inverter | STP 62-US-41 — PES Supply
1 1
Manufacturer sma america
OEM Authorized BABA Compliant Full Warranty 7-10 Business Days Delivery
Out of Stock
SKU: GAP-P2-SMASUNNYTRIPOWERCOREBrand: sma america

Out of Stock

SMA Sunny Tripower Core1 62-US 480V 62.5KW 120A String Inverter | STP 62-US-41

SMA Sunny Tripower Core1 62-US 480V 62.5KW 120A String Inverter | STP 62-US-41

$6,987.00 USD
$6,990.00 USD $6,987.00 USD
Sale Sold out
Shipping calculated at checkout.
Delivery: 7-10 business days. Freight calculated at checkout based on destination & weight.
Need a quote for this inverters? Our team can provide bulk pricing, freight quotes, and compatibility checks.
Request Quote
Return policy

Specification

  • SKU:GAP-P2-SMASUNNYTRIPOWERCORE
View full details
7-10 business days delivery from Louisville, KY
Orders ship via freight or ground from our Louisville, KY warehouse. Tracking provided once your order ships.
sma america

PES Supply is an authorized distributor for sma america. 50,000+ SKUs from 169 authorized brands.

SMA Sunny Tripower Core1 62-US 480V 62.5KW 120A String Inverter | STP 62-US-41

The sma america (US-41) is engineered for professional solar and electrical installations. Rated at 480vW. Priced below competitor at $6987.00.

Key Specifications

  • Manufacturer: sma america
  • Model: US-41
  • Category: Inverters
  • Wattage: 480vW
  • Price: $6987.00
  • Availability: In stock — same-day shipping

Order from PES Supply — your source for Tier 1 solar equipment, EOL upgrades, and electrical components. Same-day shipping by 2 PM ET. BABA compliant. Wholesale and installer pricing available.

SKUGAP-P2-SMASUNNYTRIPOWERCORE
Manufacturersma america

    No documents available for this product. Contact us to request documentation.

    SMA Sunny Tripower Core1 62-US 480V 62.5KW 120A... $6,987.00

    You May Also Need

    Outback Power FX/GS Replacement Inverter Fan Kit - FX/GS FAN KIT

    Outback Power FX/GS Replacement Inverter Fan Kit - FX/GS FAN KIT

    $33.00
    Magnum 2.8KW Battery-based Inverter - MS2812-L

    Magnum 2.8KW Battery-based Inverter - MS2812-L

    $1,925.02
    EG4 Electronics Chargeverter - GC 48V 100A 5120W Output 240/120V Input Battery Charger

    EG4 Electronics Chargeverter - GC 48V 100A 5120W Output 240/120V Input Battery Charger

    $729.92
    Outback Power Control Board - SPARE-105

    Outback Power Control Board - SPARE-105

    $276.45
    Tesla Multi Powerwall Stacking Kit - 1112154-00-B

    Tesla Multi Powerwall Stacking Kit - 1112154-00-B

    $424.23
    Tigo TS4-A-O 1500V UL/TUV 1.2M Cable MC4 700W Max Power - 461-00252-32

    Tigo TS4-A-O 1500V UL/TUV 1.2M Cable MC4 700W Max Power - 461-00252-32

    $43.17
    Outback Power System Display and Controller - MATE3s

    Outback Power System Display and Controller - MATE3s

    $572.07
    APSystems 4-Module Micro Inverter For 375W+ Modules - QS1

    APSystems 4-Module Micro Inverter For 375W+ Modules - QS1

    $336.00

    Specifications

    Datasheet
    Max Dc Voltage 1000 V
    Mppt Operating Voltage Range 150-1000 V
    Mppt Trackers 6 (2 strings each)
    Max Input Current 120 A (20 A per MPPT)
    Max Short Circuit Current 32 A per MPPT / 30 A per string
    Nominal Ac Voltage 480 V / 277 V WYE
    Ac Voltage Range 244-305 V
    Grid Frequency 60 Hz
    Phases 3
    Cec Efficiency 97.5%
    Topology Transformerless
    Cooling OptiCool (forced convection, variable speed fans)
    Enclosure Rating Type 4X, 3SX (UL 50E)
    Operating Temp -25 to +60 C
    Model STP 62-US-41
    Ac Nominal Power 62500 W
    Max Apparent Power 66000 VA
    Max Output Current 80 A
    Max Array Power 93750 Wp STC
    Rated Mpp Voltage Range 550-800 V

    Product Description

    • SMA Sunny Tripower Core1 62-US 480V 62.5KW 120A String Inverter | STP 62-US-41

      The sma america (US-41) is engineered for professional solar and electrical installations. Rated at 480vW. Priced below competitor at $6987.00.

      Key Specifications

      • Manufacturer: sma america
      • Model: US-41
      • Category: Inverters
      • Wattage: 480vW
      • Price: $6987.00
      • Availability: In stock — same-day shipping

      Order from PES Supply — your source for Tier 1 solar equipment, EOL upgrades, and electrical components. Same-day shipping by 2 PM ET. BABA compliant. Wholesale and installer pricing available.
