ACS Enerji LXR-MHC-120C-385W

ACS Enerji LXR-MHC-120C-385W

$77.00 USD
$77.00 USD
Sale Sold out
Shipping calculated at checkout.
Delivery: 7-10 business days. Freight calculated at checkout based on destination & weight.
Return policy

Specification

  • SKU:PES-SPS-SOL-0215
  • Brand: IronRidge
  • Container price: $41,580.00 USD
  • Container qty: 720
  • Mpn: LXR-MHC-120C
  • Odoo id: 18,520
  • Pallet price: $1,963.50 USD
  • Pallet qty: 30
  • Unit price: $77.00 USD
  • Manufacturer: IronRidge
  • Wattage: 385
View full details
7-10 business days delivery from Louisville, KY
Orders ship via freight or ground from our Louisville, KY warehouse. Tracking provided once your order ships.
IronRidge

PES Supply is an authorized distributor for IronRidge. 50,000+ SKUs from 169 authorized brands.

Type Monocrystalline Model No. LXR-MHC-120C-385W Product Warranty 10 Years Power Tolerance 0 ~ +1.5 % Maximum Power (Pmax) 385 Wp Voltage at Maximum Power (Vmpp) 35.15 V Current at Maximum Power (Impp) 10.95 A Open Circuit Voltage (Voc) 42.18 V Short Circuit Current (Isc) 11.55 A Panel Efficiency 21.1 % Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.36 %/°C Temperature Coefficient of Voc -0.304 %/°C Temperature Coefficient of Isc 0.05 %/°C Maximum System Voltage 1500 V Series Fuse Rating 20 A Panel Dimension (H/W/D) 1756x1039x35 mm Weight 20 kg Cell Number 120 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Download Manufacturer's PDF Datasheet

Technology: PERC
Power Range: 375 ~ 400 Wp
Panel Efficiency: 20.55 ~ 21.92 %
Weight: 20 kg
Seller Name: ACS Enerji (Lexron)
Country: Turkey

SKUPES-SPS-SOL-0215
ManufacturerIronRidge
BrandIronRidge
Container price$41,580.00 USD
Container qty720
MpnLXR-MHC-120C
Odoo id18,520
Pallet price$1,963.50 USD
Pallet qty30
Unit price$77.00 USD
ManufacturerIronRidge
Wattage385

    No documents available for this product. Contact us to request documentation.

    ACS Enerji LXR-MHC-120C-385W $77.00
