Specification
- SKU:PES-PA-ELC-24944
- Brand:
- Container price:
- Container qty:
- Mpn:
- Odoo id:
- Pallet price:
- Pallet qty:
- Unit price:
- Manufacturer:
- Wattage:
Orders ship via freight or ground from our Louisville, KY warehouse. Tracking provided once your order ships.
PES Supply is an authorized distributor for IronRidge. 50,000+ SKUs from 169 authorized brands.
Type Monocrystalline Model No. LXR-MHC-72C-230W Product Warranty 10 Years Power Tolerance 0 ~ +2.5 % Maximum Power (Pmax) 230 Wp Voltage at Maximum Power (Vmpp) 21.15 V Current at Maximum Power (Impp) 10.87 A Open Circuit Voltage (Voc) 25.38 V Short Circuit Current (Isc) 11.47 A Panel Efficiency 20.32 % Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.36 %/°C Temperature Coefficient of Voc -0.304 %/°C Temperature Coefficient of Isc 0.05 %/°C Maximum System Voltage 1000 V Series Fuse Rating 15 A Panel Dimension (H/W/D) 1581x716x30 mm Weight 13 kg Cell Number 72 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Download Manufacturer's PDF Datasheet
Technology: PERC
Power Range: 225 ~ 230 Wp
Panel Efficiency: 19.88 ~ 20.32 %
Weight: 13 kg
Seller Name: ACS Enerji (Lexron)
Country: Turkey
| SKU | PES-PA-ELC-24944 |
|---|---|
| Manufacturer | IronRidge |
| Brand | |
| Container price | |
| Container qty | |
| Mpn | |
| Odoo id | |
| Pallet price | |
| Pallet qty | |
| Unit price | |
| Manufacturer | |
| Wattage |
No documents available for this product. Contact us to request documentation.
You May Also Need
Specifications
Product Description
-
Type Monocrystalline Model No. LXR-MHC-72C-230W Product Warranty 10 Years Power Tolerance 0 ~ +2.5 % Maximum Power (Pmax) 230 Wp Voltage at Maximum Power (Vmpp) 21.15 V Current at Maximum Power (Impp) 10.87 A Open Circuit Voltage (Voc) 25.38 V Short Circuit Current (Isc) 11.47 A Panel Efficiency 20.32 % Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.36 %/°C Temperature Coefficient of Voc -0.304 %/°C Temperature Coefficient of Isc 0.05 %/°C Maximum System Voltage 1000 V Series Fuse Rating 15 A Panel Dimension (H/W/D) 1581x716x30 mm Weight 13 kg Cell Number 72 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Download Manufacturer's PDF Datasheet
Technology: PERC
Power Range: 225 ~ 230 Wp
Panel Efficiency: 19.88 ~ 20.32 %
Weight: 13 kg
Seller Name: ACS Enerji (Lexron)
Country: Turkey -
