AESOLAR 530W-1
PayPal Pay in 4 interest-free payments of $26.50 on qualifying orders, or monthly financing with PayPal Pay Later.
Available at checkout for eligible US buyers. Subject to approval.
Ships by freight. Carrier checkout rates can’t price this correctly — we quote the exact delivered rate to your ZIP.
Orders ship via freight or ground from our Louisville, KY warehouse. Tracking provided once your order ships.
Ships via LTL freight — palletized, liftgate available. Our team confirms freight details within 1 business day.
Secure checkout · Wire/ACH accepted on quotes · Freight arranged for you
Transit estimates from Louisville, KY. Freight details →
- SKU
- PES-SPS-SOL-0319
- Unit price
- $0.20/W
Complete the job
Compatible gear contractors pair with this item
PES Supply is an authorized distributor for PES Global. 50,000+ SKUs from 169 authorized brands.
Type Monocrystalline Model No. 530W-1 Product Warranty 12 Years Power Warranty 25 Years of 84.8 % Total Degradation Rate ⏳ 0.61 % Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 530 Wp Voltage at Maximum Power (Vmpp) 45.62 V Current at Maximum Power (Impp) 11.6 A Open Circuit Voltage (Voc) 52.91 V Short Circuit Current (Isc) 12.4 A Panel Efficiency 20.68 % Maximum Power (Pmax) 394 Wp Voltage at Maximum Power (Vmpp) 42.11 V Current at Maximum Power (Impp) 9.36 A Open Circuit Voltage (Voc) 50 V Short Circuit Current (Isc) 10.01 A Temperature 45±2 °C Operating Temperature Range -40 - +85 °C Temperature Coefficient of Pmax -0.3 %/°C Temperature Coefficient of Voc -0.275 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 24 A Panel Dimension (H/W/D) 2278x1134x30 mm Weight 26.5 kg Cell Size 182×91 mm Cell Number 144 Glass Type Anti-reflection Coating, Tempered Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 C
Technology: BIPV
Power Range: 495 ~ 530 Wp
Panel Efficiency: 19.31 ~ 20.68 %
Weight: 26.5 kg
Seller Name: AE Alternative Energy GmbH
Country: Germany
| SKU | PES-SPS-SOL-0319 |
|---|---|
| Manufacturer | PES Global |
| Container price | |
| Container qty | |
| Odoo id | |
| Pallet price | |
| Pallet qty | |
| Unit price | |
| Manufacturer | |
| Wattage |
No documents available for this product. Contact us to request documentation.
