CNBM SKT460M10 460W PERC Monocrystalline Solar Panel
SKT460M10 | PERC Technology | 120 Cells Monocrystalline | Mono | 1500V System Voltage
Product Overview
The CNBM SKT460M10 460W PERC Monocrystalline Solar Panel delivers exceptional energy performance for modern solar installations. This high-efficiency module features advanced PERC technology paired with premium 182mm monocrystalline cells. It achieves a remarkable 21.1% module efficiency while generating up to 460 watts of maximum power under standard test conditions. The panel utilizes 120 half-cut cells to reduce internal resistance and improve low-light performance. Its robust construction includes tempered anti-reflection glass and an anodized aluminum frame for long-term durability. Designed for both residential and commercial applications, this solar panel offers a 25-year power warranty and a 12-year product warranty. The 1500V maximum system voltage supports flexible grid-tie configurations. Its compact dimensions of 1909x1134x35mm allow for efficient space utilization on rooftops or ground mounts. This reliable solution ensures consistent energy generation even in challenging weather conditions.
Key Benefits
High Power Output: Generates up to 460 watts of maximum power for superior energy production.
Advanced PERC Technology: Uses Passivated Emitter and Rear Cell tech to boost efficiency and low-light response.
Exceptional Durability: Built with tempered glass and anodized aluminum to withstand 5400Pa mechanical load.
Long Warranty Period: Includes a 25-year power warranty and 12-year product warranty for peace of mind.
Optimized Cell Design: Features 120 half-cut 182mm cells to reduce resistance and improve performance.
How It Works
This solar panel converts sunlight into electricity through its advanced photovoltaic cell structure. The PERC technology enhances electron collection by adding a passivation layer on the rear side of each cell. This design minimizes energy loss and significantly improves overall module efficiency. The half-cut cell configuration reduces internal resistance, allowing better current flow even in partial shading. The anti-reflection coating on the tempered glass maximizes light absorption across the entire spectrum. These combined features ensure reliable energy generation from early morning until late evening. The robust construction protects internal components from environmental stress and mechanical loads.
PERC Cell Enhancement: The passivation layer on the rear reduces electron recombination. This increases voltage output and boosts total efficiency by capturing more photons.
Half-Cut Cell Advantage: Cutting cells in half lowers internal resistance significantly. This design improves current flow and reduces power loss under shading conditions.
Anti-Reflection Coating: The special glass coating minimizes light reflection. This allows more sunlight to penetrate the cells for maximum energy conversion.
Technical Specifications
| Maximum Power (Pmax) | 460 Wp |
| Module Efficiency | 21.1% |
| Cell Technology | PERC Monocrystalline |
| Cell Count | 120 Half-Cut Cells |
| Cell Size | 182 x 182 mm |
| Voltage at Pmax (Vmpp) | 35.16 V |
| Current at Pmax (Impp) | 13.08 A |
| Open Circuit Voltage (Voc) | 41.84 V |
| Short Circuit Current (Isc) | 13.99 A |
| Power Tolerance | 0 to +1% |
| Maximum System Voltage | 1500 Vdc |
| Series Fuse Rating | 25 A |
| Dimensions (H/W/D) | 1909 x 1134 x 35 mm |
| Weight | 24 kg |
| Front Glass | 3.2 mm Tempered AR Coated |
| Frame Type | Anodized Aluminum Alloy |
| Junction Box Protection | IP68 |
| Operating Temperature Range | -40°C to +85°C |
| Nominal Operating Cell Temp | 45 ± 2°C |
| Pmax Temp Coefficient | -0.35%/°C |
| Voc Temp Coefficient | -0.275%/°C |
| Isc Temp Coefficient | +0.045%/°C |
| Mechanical Load Front | 5400 Pa |
| Mechanical Load Rear | 2400 Pa |
| Output Cable Size | 4.0 mm² (50cm + / 50cm -) |
| Connector Type | MC4 Compatible |
| Total Degradation Rate | 84.8% after 25 Years |
Certifications & Compliance
Certifications: IEC 61215, IEC 61730, UL 61730, TUV Certified
Inverter Compatibility: Compatible with all major string inverters (1500Vdc systems)
Environmental: Anti-PID, Anti-LID, Low-light performance, 100% Inspection
Warranty: 25-Year Power Warranty (84.8% output), 12-Year Product Warranty
