Enphase IQ-AM1-240-4

Enphase IQ8 X-AC Combiner with IQ Envoy - IQ-AM1-240-4

The Enphase IQ8 X-AC Combiner with IQ Envoy, designated as model IQ-AM1-240-4, is designed for seamless integration with Enphase devices. This innovative product not only simplifies installation processes for solar energy systems but also enhances performance monitoring capabilities. By using this combiner, users can maximize the efficiency of their solar setups, ensuring optimal power management and system monitoring.

Product Features

Integrated IQ Gateway

The IQ8 Combiner comes equipped with a built-in IQ Gateway, which facilitates easy communication between the solar energy system and the Enphase Cloud. This feature ensures that users can monitor their system's performance in real-time, directly from their mobile devices.

Supports Multiple AC Branch Circuits

This model supports the connection of up to four AC branch circuits of Enphase IQ Series Microinverters and batteries. This versatility allows for enhanced scalability and flexibility, catering to various installation configurations.

Durable Outdoor-Rated Enclosure

Constructed with a NEMA type 3R enclosure, the IQ8 is built to withstand outdoor environments, providing reliable performance and protection against the elements, which is essential for system longevity.

Streamlined Installation Process

The combiner is designed for easy installation, requiring only basic tools, which simplifies the process for technicians and reduces installation time. This feature is fundamental for both residential and commercial applications.

Real-Time Performance Monitoring

With integrated monitoring capabilities, users can track system performance metrics, enabling timely adjustments and maintenance. This feature ensures maximized energy production and reliability in operation.

How It Works

The Enphase IQ8 X-AC Combiner operates as a central hub for managing multiple solar connections and integrating with Enphase Microinverters or batteries. By facilitating both power distribution and communication, it ensures that energy flows smoothly and is monitored accurately.

Connection Management

This component manages the output connections from the microinverters, allowing efficient distribution of solar power while maintaining safety and compliance with local electrical codes.

Performance Monitoring

The IQ Gateway enables real-time performance data to be relayed to the Enphase Cloud, where users can access their system's statistics and receive alerts about performance issues.

Connectivity Options

This unit supports various connectivity options, including Wi-Fi and Ethernet, ensuring dependable communication with the Enphase monitoring platform, which is essential for efficient energy management.

Specifications

Specification Title	Specification Value
Model Number	IQ-AM1-240-4
Manufacturer	Enphase
Enclosure Type	NEMA type 3R
Max Branch Circuits	4 AC Branch Circuits
Installation Method	Wall-Mountable
Monitoring Capability	Real-Time Performance Monitoring
Compatibility	Enphase IQ Microinverters and batteries
Input Voltage	240V AC
Operation Temperature	-40°C to 65°C
Weight	Weight varies by configuration
