Isola New Energy YH550W-36MH
Isola New Energy YH550W-36MH
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-9236
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. YH550W-36MH Power Warranty 30 Years of 90 % Total Degradation Rate ⏳ 0.33 % Power Tolerance 0 ~ +0.5 % Maximum Power (Pmax) 550 Wp Voltage at Maximum Power (Vmpp) 42.13 V Current at Maximum Power (Impp) 13.06 A Open Circuit Voltage (Voc) 50.1 V Short Circuit Current (Isc) 13.9 A Panel Efficiency 21.28 % Maximum Power (Pmax) 408 Wp Voltage at Maximum Power (Vmpp) 39.09 V Current at Maximum Power (Impp) 10.46 A Open Circuit Voltage (Voc) 46.92 V Short Circuit Current (Isc) 11.2 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.35 %/°C Temperature Coefficient of Voc -0.27 %/°C Temperature Coefficient of Isc 0.048 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2279x1134x30 mm Weight 27 kg Cell Size 182×91 mm Cell Number 144 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Datasheet
Technology: PERC
Power Range: 550 Wp
Panel Efficiency: 21.28%
Weight: 27 kg
Seller: Zhejiang Isola New Energy Co., Ltd.
Country: China -
