    SunEvo Solar SE5-72H-540W

    SunEvo Solar SE5-72H-540W

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-18836
    • Container price: $43.20 USD
    • Container qty: 720
    • Pallet price: $2.04 USD
    • Pallet qty: 30
    • Unit price: $0.08 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. SE5-72H-540W Product Warranty 12 Years Power Warranty 25 Years of 84.80 % Total Degradation Rate ⏳ 0.61 % Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 540 Wp Voltage at Maximum Power (Vmpp) 42.06 V Current at Maximum Power (Impp) 12.84 A Open Circuit Voltage (Voc) 49.75 V Short Circuit Current (Isc) 13.63 A Panel Efficiency 21.1 % Maximum Power (Pmax) 408.6 Wp Voltage at Maximum Power (Vmpp) 39.01 V Current at Maximum Power (Impp) 10.47 A Open Circuit Voltage (Voc) 46.96 V Short Circuit Current (Isc) 10.92 A Temperature 43±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.36 %/°C Temperature Coefficient of Voc -0.28 %/°C Temperature Coefficient of Isc 0.05 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2279x1134x35 mm Weight 26.9 kg Cell Number 144 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector T

      Technology: PERC
      Power Range: 540 ~ 560 Wp
      Panel Efficiency: 21.1 ~ 21.9 %
      Weight: 26.9 kg
      Seller Name: SunEvo Solar Co., Ltd.
      Country: China
