Alpex Solar ALP24L 545WM Monocrystalline PERC Solar Panel
Model ALP24L 545WM | PERC | 144 Half-Cut Cells | Monocrystalline | 1500V System Voltage
Product Overview
The Alpex Solar ALP24L 545WM is a high-performance monocrystalline PERC solar panel built for strong energy yield and dependable long-term use. It delivers a maximum power rating of 545 Wp and a module efficiency of 21.12 percent. The 144 half-cut cell design supports stable output and improved electrical performance. Its large-format construction is suited for demanding commercial and utility-scale solar installations. The panel is engineered with an anti-reflection tempered glass surface, an anodized aluminium frame, and IP67 protection for enhanced durability. It is also designed for a 1500V system voltage, which supports efficient string design. With a 10-year warranty for 90 percent output and a 25-year warranty for 80 percent output, it offers dependable value over time.
Key Benefits
High Power Output: The panel delivers 545 Wp for strong generation from a single module.
High Efficiency: Its 21.12 percent efficiency helps maximize output within available roof or ground space.
Half-Cut Cell Design: The 144-cell half-cut layout supports improved current handling and better performance stability.
Durable Construction: Tempered glass, EVA encapsulant, and an anodized aluminium frame improve mechanical strength.
Long-Term Reliability: The product is backed by a 10-year and 25-year performance warranty structure.
Installation-Friendly Design: MC4-compatible connectors and a 4 mm2 cable simplify system integration.
How It Works
The ALP24L 545WM converts sunlight into usable electricity through monocrystalline PERC cell technology. Light strikes the anti-reflection tempered glass, which helps reduce surface losses and improve absorption. The 144 half-cut cells then generate direct current with balanced electrical flow. This design helps limit resistance and supports steady output under real-world conditions. The module is intended for string-connected systems using a 1500V architecture. That allows efficient deployment in larger solar arrays. Heat management is supported through temperature coefficients that help explain performance changes in warmer conditions. The result is a panel built for consistent power delivery, efficient installation, and dependable system operation.
Sunlight Conversion: Monocrystalline PERC cells convert incoming sunlight into electrical energy. The panel is designed to capture and process solar radiation efficiently.
Half-Cut Cell Flow: The 144 half-cut cell structure reduces current pathways. This supports lower resistive losses and improved output stability.
System Integration: The module is built for 1500V system designs with MC4-compatible connectors. This makes it suitable for larger commercial and utility installations.
Technical Specifications
| Brand | Alpex Solar |
| Model Number | ALP24L 545WM |
| Technology | PERC |
| Cell Type | Monocrystalline, 144 Half-Cut Cells |
| Power Range | 520 to 555 Wp |
| Maximum Power (Pmax) | 545 Wp |
| Voltage at Maximum Power (Vmpp) | 41.79 V |
| Current at Maximum Power (Impp) | 13.05 A |
| Open Circuit Voltage (Voc) | 49.75 V |
| Short Circuit Current (Isc) | 13.91 A |
| Module Efficiency | 21.12% |
| Maximum System Voltage | 1500 V |
| Series Fuse Rating | 25 A |
| Panel Dimensions | 2278 x 1133 x 35 mm |
| Weight | 29 kg |
| Glass Type | Anti-reflection coated tempered glass |
| Encapsulant Type | EVA |
| Frame Type | Anodized aluminium |
| Junction Box | 3 bypass diodes, IP67 protection class |
| Connector Type | MC4 |
| Cable Cross Section | 4 mm2 |
| Cable Length | 300 mm |
| Operating Temperature Range | -40 to 85 °C |
| NOCT | 45 ± 2 °C |
| Temperature Coefficient of Pmax | -0.35 %/°C |
| Temperature Coefficient of Voc | -0.27 %/°C |
| Temperature Coefficient of Isc | 0.045 %/°C |
| Mechanical Load Test | 5400 Pa snow load, 2400 Pa wind load |
| Seller Name | Alpex Solar Limited |
| Country of Origin | India |
Certifications & Compliance
Certifications: ALMM, IEC, BIS
Inverter Compatibility: Suitable for 1500V string inverter systems
Environmental: Designed for -40 to 85 °C operating conditions with IP67 junction box protection
Warranty: 10 years for 90 percent output and 25 years for 80 percent output
