    ACS Enerji LXR-MHC-144C-460W

    ACS Enerji LXR-MHC-144C-460W

    $92.00 USD
    $92.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-0224
    • Brand: IronRidge
    • Container price: $49,680.00 USD
    • Container qty: 720
    • Mpn: LXR-MHC-144C
    • Odoo id: 18,069
    • Pallet price: $2,346.00 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. LXR-MHC-144C-460W Product Warranty 10 Years Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 460 Wp Voltage at Maximum Power (Vmpp) 42.3 V Current at Maximum Power (Impp) 10.87 A Open Circuit Voltage (Voc) 50.76 V Short Circuit Current (Isc) 11.47 A Panel Efficiency 21.12 % Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.35 %/°C Temperature Coefficient of Voc -0.27 %/°C Temperature Coefficient of Isc 0.048 %/°C Maximum System Voltage 1500 V Series Fuse Rating 20 A Panel Dimension (H/W/D) 2096x1039x35 mm Weight 24 kg Cell Number 144 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Download Manufacturer's PDF Datasheet

      Technology: PERC
      Power Range: 435 ~ 460 Wp
      Panel Efficiency: 19.97 ~ 21.12 %
      Weight: 24 kg
      Seller Name: ACS Enerji (Lexron)
      Country: Turkey
