GoodWe GW50K-SMT-US — 50 kW, 480 V Three-Phase (SMT-US Series)

GoodWe SMT-US Series 480V Commercial Inverter - GW50K-SMT-US TIGO is a high-performance three-phase inverter engineered specifically for large commercial and industrial solar installations. Designed to deliver exceptional efficiency, grid compatibility, and system intelligence, this inverter supports demanding energy environments while ensuring long-term reliability. Its advanced design makes it a strong choice for businesses seeking optimized solar power generation at scale.

Flagship 480 V C&I string inverter with up to 5 MPPTs (2 inputs each), wide 180–980 Vdc MPPT range, NEMA Type 4X enclosure, integrated AFCI and Type II SPDs, and Rapid Shutdown integrated (PVRSS). “TIGO” channel SKUs indicate the factory variant with a Tigo RSS transmitter. :contentReference[oaicite:7]{index=7}

Technical Specifications — from GoodWe SMT-US Datasheet

Input (DC)
Max. input voltage 1000 V
MPPT operating voltage range 180 ~ 980 V
Start-up voltage 200 V
Nominal input voltage 720 V
Max. input current per MPPT 30 A
Max. short-circuit current per MPPT 50 A
Number of MPP trackers 5
Strings per MPPT 2
Output (AC)
Nominal output power 50 kW
Nominal apparent power 50 kVA
Max. AC active power 55 kW
Max. AC apparent power 55 kVA
Nominal AC grid voltage 480 V, 3L/N/PE or 3L/PE
Nominal grid frequency 60 Hz
Max. output current 67 A
Power factor ~1 (adjustable 0.8 leading … 0.8 lagging)
Max. THD < 3%
Efficiency
Max. efficiency 98.5%
CEC efficiency 98.2%
Protection & Safety
PV string current monitoring Integrated
PV insulation resistance detection Integrated
Residual current monitoring Integrated
PV reverse-polarity protection Integrated
Anti-islanding protection Integrated
AC overcurrent / short-circuit / overvoltage Integrated
DC switch / AC switch Integrated
DC surge protection Type II
AC surge protection Type II
AFCI Integrated (AI-driven)
Rapid Shutdown Integrated (PVRSS per NEC 690.12 / CEC 64-218)
General
Operating temperature −30 ~ +60 °C (derate > +45 °C)
Operating temperature (°F) −22 ~ +140 °F (derate > +113 °F)
Relative humidity 0 ~ 100%
Max. operating altitude 4000 m (derate > 3000 m) / 13123 ft (derate > 9842.5 ft)
Cooling Smart fan cooling
Display / Monitoring LED, WLAN + App
Communication RS485, Wi-Fi, USB, 4G or Wi-Fi + LAN (optional)
Protocols Modbus-RTU (SunSpec compliant)
Noise < 65 dB(A)
Topology Non-isolated
Night self-consumption < 12 W* (*<1 W without optional RSD & 24-hr load monitoring.)
Enclosure rating NEMA Type 4X
DC connector #12 ~ #8 AWG (Cu)
AC connector OT (#5–3/0 AWG, Cu or Al)
Weight 70 kg (154.3 lb)
Dimensions (W × H × D) 520 × 990 × 220 mm (20.5 × 39.0 × 8.7 in)
Compliance
Certifications UL1741 (Third Edition), IEEE 1547-2018 / 1547.1-2020 / 1547a-2020; CSA C22.2 No.0.8-19 & UL 1998 Ed.3; PVRSS per NEC-2020 690.12 & CEC-2018 Sec 64-218; IEEE 2030.5-2018

All electrical/mechanical/safety data from the official SMT-US datasheet; “Tigo Transmitter” variant (for channels listing ‘TIGO’) confirmed via distributor catalog (SMT0050-64-01P). :contentReference[oaicite:8]{index=8}

Built for High-Capacity Commercial Solar Systems

The GoodWe SMT-US Series 480V Commercial Inverter - GW50K-SMT-US TIGO is purpose-built for 480V commercial applications, making it suitable for warehouses, factories, office complexes, and large retail facilities. With a robust 50kW output, it enables higher energy production while reducing balance-of-system costs. The inverter supports large DC input capacity, allowing installers to maximize array design flexibility and overall system performance.

Its transformerless topology improves efficiency while reducing system weight and installation complexity. This makes deployment faster and more cost-effective, especially for large rooftop and ground-mounted solar projects.

Advanced Efficiency and Power Optimization

Efficiency is a defining feature of this inverter. The system delivers high conversion efficiency, minimizing energy loss during DC-to-AC conversion. Integrated compatibility with TIGO optimization technology enhances module-level performance, allowing improved energy harvest even in partial shading or complex rooftop layouts.

The intelligent Maximum Power Point Tracking (MPPT) system ensures consistent output throughout the day by adapting to varying solar conditions. Multiple MPPT channels allow flexible panel configurations and better yield optimization across diverse installation environments.

Grid Compliance and Operational Stability

The GoodWe SMT-US Series 480V Commercial Inverter - GW50K-SMT-US TIGO is engineered to meet strict North American grid requirements. It supports advanced grid support functions, including reactive power control, voltage ride-through, and frequency response. These capabilities ensure stable operation even during grid disturbances and help commercial systems remain compliant with evolving utility standards.

The inverter also features low total harmonic distortion (THD), contributing to cleaner power output and reduced stress on connected electrical equipment. This enhances system longevity and operational reliability for commercial users.

Smart Monitoring and System Management

Intelligent monitoring capabilities enable real-time system visibility and remote performance management. The inverter supports advanced communication protocols, allowing seamless integration with energy management systems. Operators can track performance metrics, identify faults, and optimize output without on-site intervention.

Built-in safety features such as DC reverse polarity protection, anti-islanding, and arc-fault detection further enhance operational security. These protections reduce risk, minimize downtime, and ensure compliance with safety regulations.

Durable Design for Long-Term Performance

Commercial solar installations demand durability, and this inverter delivers. The enclosure is designed to withstand harsh environmental conditions, including temperature fluctuations and dust exposure. Active cooling technology ensures optimal thermal performance, preventing overheating and maintaining consistent efficiency even under heavy load.

High-quality internal components extend service life, reducing maintenance requirements and improving overall return on investment. This reliability makes the inverter suitable for long-term commercial energy strategies.

Scalable Solution for Growing Energy Needs

As energy demands increase, scalability becomes essential. The GoodWe SMT-US Series 480V Commercial Inverter - GW50K-SMT-US TIGO supports modular system expansion, allowing businesses to scale solar capacity without replacing existing infrastructure. This future-ready design makes it an ideal choice for enterprises planning phased solar deployment.

Why Choose This Commercial Inverter?

  • Optimized for 480V commercial and industrial solar systems
  • High efficiency with advanced MPPT technology
  • TIGO compatibility for enhanced module-level performance
  • Strong grid compliance and intelligent safety features
  • Durable construction for long-term reliability
  • Scalable architecture for expanding energy demands

With its combination of performance, intelligence, and durability, this inverter stands out as a dependable solution for modern commercial solar installations.
