Techwise Solar 545W
PayPal Pay in 4 interest-free payments of $47.75 on qualifying orders, or monthly financing with PayPal Pay Later.
Available at checkout for eligible US buyers. Subject to approval.
Ships by freight. Carrier checkout rates can’t price this correctly — we quote the exact delivered rate to your ZIP.
Orders ship via freight or ground from our Louisville, KY warehouse. Tracking provided once your order ships.
Ships via LTL freight — palletized, liftgate available. Our team confirms freight details within 1 business day.
Secure checkout · Wire/ACH accepted on quotes · Freight arranged for you
Transit estimates from Louisville, KY. Freight details →
- SKU
- PES-SPS-SOL-20711
- Unit price
- $0.35/W
Complete the job
Compatible gear contractors pair with this item
PES Supply is an authorized distributor for ENF Solar. 50,000+ SKUs from 169 authorized brands.
Type Monocrystalline Model No. 545W Product Warranty 12 Years Power Warranty 25 Years of 84.8 % Total Degradation Rate ⏳ 0.61 % Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 545 Wp Voltage at Maximum Power (Vmpp) 41.85 V Current at Maximum Power (Impp) 13.03 A Open Circuit Voltage (Voc) 49.7 V Short Circuit Current (Isc) 13.91 A Panel Efficiency 21.09 % Maximum Power (Pmax) 412 Wp Voltage at Maximum Power (Vmpp) 39.14 V Current at Maximum Power (Impp) 10.53 A Open Circuit Voltage (Voc) 46.59 V Short Circuit Current (Isc) 11.17 A Temperature 44±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.35 %/°C Temperature Coefficient of Voc -0.275 %/°C Temperature Coefficient of Isc 0.05 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2279x1134x35 mm Weight 27 kg Cell Size 182×182 mm Cell Number 144 Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 C
Technology: PERC
Power Range: 530 ~ 555 Wp
Panel Efficiency: 20.51 ~ 21.48 %
Weight: 27 kg
Seller Name: Techwise Solar Technology Co., Ltd.
Country: China
| SKU | PES-SPS-SOL-20711 |
|---|---|
| Manufacturer | ENF Solar |
| Container price | |
| Container qty | |
| Pallet price | |
| Pallet qty | |
| Unit price | |
| Manufacturer | |
| Wattage |
No documents available for this product. Contact us to request documentation.
