What is the Victron Energy ASS300420100 used for?

The Victron Energy ASS300420100 is used to convert Zigbee wireless communication into RS485 wired signals, enabling seamless data exchange between Zigbee-enabled devices and RS485-based systems.

Is the Victron Zigbee to RS485 converter suitable for industrial use?

Yes, it is designed for both industrial and home automation environments, featuring a wide temperature range and stable performance in demanding conditions.

What power supply does the ASS300420100 require?

The converter operates on a DC power range of 5V to 12V, providing flexibility for different installation setups.

What communication protocols does this converter support?

It supports the Zigbee2007 protocol, ensuring compatibility with a wide range of Zigbee-based devices.

How far can the Victron Zigbee to RS485 converter transmit data?

The device supports an open-area transmission distance of up to 1600 meters, making it ideal for large-scale installations.

Home
Victron Energy Solar Kits — Performance Picks
Victron Zigbee to RS485 converter - ASS300420100

Victron Zigbee to RS485 converter - ASS300420100 — front view

Available to Order

Order today — we confirm lead time at checkout

Volume Pricing

Call 888-876-0007 for a pallet-quote

Flat Rate Shipping - Calculated at Checkout

Delivery timeframe shown above at checkout

Lifetime Customer Support

Unlimited lifetime support, always available.

Victron Zigbee to RS485 converter - ASS300420100

Trusted by 1,000s of Contractors & Installers

Available to Order

SKU PES-PA-ELC-0521

OEM Authorized Dealer Full OEM Warranty

$127.00 USD

$ $127.00 USD

Sold out

Quantity

Datasheet

Multi-unit or project order?Get a Volume Quote →

Offloading overstock or decommissioned gear? We buy surplus equipment →

Secure checkout · Wire/ACH accepted on quotes · Freight arranged for you

Ships via ground carrier, tracked. Pallet & heavy orders go LTL freight — our team confirms freight within 1 business day.

SKU: PES-PA-ELC-0521
MPN: ASS300420100
Min purchase: 10 pcs

Complete the job

Compatible gear contractors pair with this item

Solar panels Runergy Hyperion 400W Mono PERC Bifacial Dual Glass HY-DH108P8B-400 Solar Panel

$140.99

Secure Payment Methods

Available to Order

Order today — we confirm lead time at checkout

Volume Pricing

Call 888-876-0007 for a pallet-quote

Flat Rate Shipping - Calculated at Checkout

Delivery timeframe shown above at checkout

Lifetime Customer Support

Unlimited lifetime support, always available.

Request a Free Quote

Got Questions? We’re Here to Help!

Our support team is ready to assist you with product guidance, order details, or any questions you might have.

(888) 876-0007

Instant Live Chat

Mon-Fri 10am-6pm EST

View full details

Victron Zigbee to RS485 converter - ASS300420100 $127.00

Certifications<

What is your return policy?

Returns are free in the first 30 days with no restocking or processing fees, although the customer may be responsible for paying return shipping. See our complete return policy on our Shipping, Delivery, and Returns page linked in the footer of this website.

What’s covered by your return policy?

Our returns policy covers all purchases made through Portlandia Electric Supply. For warranty issues, as authorized distributors, we honor the full manufacturer warranty of ALL the brands on our website. See our complete returns and warranty policies on our Shipping, Deliver, and Returns page.

How long will it take to receive my order?

All orders are processed within 72 hours and you can expect delivery on most orders within 5-7 business days. You will receive access to our customer portal after ordering, where it is easy to track all your shipments. See our Shipping, Delivery and Returns page for more details.

What are your financing and payment options?

We offer several ways to pay to make getting your solar kit simple:

Credit Card: if the purchase is greater than your card’s limit, you can split the cost onto multiple cards as well as Paypal, financing through Affirm, and ACH/bank transfer

You can arrange financing during the checkout process, or scroll further down this page for more details. Please note, if you'd like to finance your order, you can do so instantly, right at checkout.

How does your Lifetime Customer Support work?

Our legendary lifetime customer support has helped make us the #1 online solar retailer! We have a dedicated team of solar professionals standing by to help you navigate the world of solar with ease. From selecting the perfect solar kit to installation and beyond, we provide support and expertise at every step of the journey.If you need help with ordering, shipping, troubleshooting, expanding your system, warranty issues, or anything else you have questions about for as long as you own your Portlandia Electric Supply equipment, we’ve got you covered: we’re always only a phone call or email away.

Victron Zigbee to RS485 Converter - ASS300420100

The Victron Energy ASS300420100 is a premier Zigbee to RS485 converter designed to streamline communication between Zigbee-based devices and RS485 systems. With its reliable performance and easy integration capabilities, this converter ensures efficient data transmission, making it ideal for both industrial and home automation applications. Moreover, it comes equipped with various features designed to enhance user experience and operational efficiency.

Product Features

Power Versatility

This converter operates on a wide power standard ranging from DC 5 to 12V, allowing flexible deployment in various environments while ensuring consistent performance across all devices. The power versatility simplifies installation and maintenance, making the ASS300420100 a convenient choice for users.

Expanded Temperature Range

With a robust temperature range from -40°C to 85°C, the Victron Zigbee to RS485 converter can operate effectively in harsh environmental conditions. This feature ensures durability and reliability, reinforcing its suitability for outdoor or exposed installations.

High Data Rate Options

Users can select from multiple UART baud rates, including the default 38400bps, or opt for 9600bps, 19200bps, 57600bps, and 115200bps as needed. This flexibility allows users to optimize data transmission speeds tailored to their specific application requirements.

Long Transmission Distance

The device can achieve an impressive open transmission distance of up to 1600 meters, facilitating extensive networking capabilities. This feature is particularly beneficial for larger installations where devices are spread over a wide area, ensuring reliable communication without signal degradation.

Multiple Protocol Compatibility

Compatible with Zigbee2007 protocol, the ASS300420100 ensures seamless integration with a plethora of Zigbee devices. This compatibility enhances connectivity options and facilitates easy setup in various industrial and residential applications.

How It Works

The Victron Zigbee to RS485 converter functions by translating signals between Zigbee wireless networks and RS485 wired devices. This process allows devices using different communication protocols to interact seamlessly, providing a robust solution for mixed-environment setups.

Signal Conversion Mechanism

The core component of this converter is its advanced signal processing technology, which efficiently translates Zigbee packets into RS485 signals and vice versa. This ensures that data integrity is maintained throughout the conversion process.

Enhanced Receiver Sensitivity

With a receiver sensitivity of -110dBm, the converter can detect weaker signals, ensuring reliable communication even in challenging conditions. This sensitivity contributes to the overall robustness of the networking solution.

Integration-Friendly Design

Designed with ease of integration in mind, the ASS300420100 comes equipped with a user-friendly interface that simplifies setup. The RS485 interface with B, A, and GND connections ensures compatibility with standard wiring systems, making installation straightforward.

Specifications

Power Standard	DC 5 - 12V
Temperature Range	-40°C to 85°C
UART Baud Rate	9600bps, 19200bps, 38400bps, 57600bps, 115200bps (Default: 38400bps)
Radio Frequency	2460MHz (Default), 2405MHz - 2480MHz, Step: 5MHz
Protocol	Zigbee2007
Visible Transmission Distance	1600 meters
Operating Current (Send)	120mA (Max)
Operating Current (Receive)	45mA (Max)
Standby Current	40mA (Max)
Receiver Sensitivity	-110dBm
Chip Model	CC2530F256, 256KFLASH
Node Configuration	Configured Node: Coordinator, Router
Default Settings	Router, PAN ID=0x199B, Channel=22 (2460MHz)
Size	705024mm
