Victron Energy VBS127010010

The Victron Energy Battery Switch 275A is an essential accessory for managing battery systems up to 48V. Designed with a unique ergonomic knob for effortless handling, it allows users to isolate batteries from both DC loads and charging sources, ensuring efficiency and safety in power management. This switch is perfect for preserving battery charge during unattended periods, maintenance, or emergencies, making it a reliable asset for any user.

Product Features

Ergonomic Design

The Battery Switch features an easy-to-use ergonomic knob, enhancing user experience and allowing for quick operation. This thoughtful design emphasizes convenience and accessibility, making it simple to manage your battery systems effectively.

Versatile Applications

This versatile Battery Switch can isolate batteries from DC systems and serve as a parallel connection to allow the house battery to support the starter battery in emergencies. It is designed to ensure efficient energy management in critical situations.

Flexible Installation Options

The Battery Switch offers flexibility in installation with options for surface or panel mounting. Its four removable side panels make cable access straightforward, providing adaptability for different setups and configurations.

Safety Features

Safety is paramount with this Battery Switch, including a removable knob for isolation when necessary. The switch meets ISO8846 Ignition Protection standards, making it suitable for use in engine rooms, ensuring safety during operation.

Included Label Stickers

The Battery Switch comes with 16 customizable label stickers, allowing users to personalize the switch for their specific needs. This feature enhances usability and helps in visual identification of the switch's function.

How It Works

The Victron Energy Battery Switch operates by enabling or disabling battery connections with a simple knob rotation. The main components work seamlessly to ensure safe and effective battery management while providing quick access to connect or isolate batteries as necessary.

Knob Mechanism

The removable knob mechanism allows immediate isolation of the battery, providing users with quick access to safety features. This ensures that the system remains under control during maintenance or emergencies.

Cable Access Panels

The four easily removable cable access panels provide users with a straightforward pathway for installation and maintenance. This component ensures that users can manage and troubleshoot their battery connections without hassle.

Compliance with Safety Standards

This Battery Switch adheres to strict safety standards such as ISO8846, ensuring that it is built for use in environments where ignition protection is critical. This compliance underscores its reliability and professional-grade performance.

Specifications

Max Continuous Current 275 A
One Minute Rating 455 A
Cranking Rating 1250 A
Voltage Rating 48 V
Terminal Material Tin-plated copper
Hex Nut Material Tin-plated copper
Terminal Diameter 3/8 inch / 9.53 mm
Recommended Torque 70 lbfA‚·inch / 8 NA‚·m
Base Material Glass fiber reinforced nylon
Weight 0.4 lb / 0.2 kg
Dimensions (L x W x H) 2.7 x 3.0 x 2.7 inch / 69.5 x 76.3 x 69.5 mm
Mounting Type Surface or rear panel mount
Ignition Protection ISO8846 / SAE J1171

Specifications & Documents: Full specifications & datasheet for Victron Battery switch on/off 275A - VBS127010010
