SimpliPhi Power

SimpliPhi battery systems

SimpliPhi builds lithium iron phosphate battery modules aimed at off-grid, mobile and resilient backup systems, with a reputation for deep cycling and a deep case form factor that fits tight equipment rooms. This collection carries 91 SKUs, 84 of them SimpliPhi, from single modules to complete banks.

Designing around SimpliPhi modules

• Usable capacity. Plan on 80-90% depth of discharge. A bank's usable kWh, not nameplate, is what runs the load through the night.
• Charge profile. LFP wants a charger it can bulk-charge and then float low; confirm the inverter/charger has a lithium profile and can be set to the manufacturer's voltages.
• Series and parallel limits. Match the system voltage (48V is standard above small systems) and confirm the maximum parallel count and interconnect hardware from the datasheet.
• Temperature. LFP does not want to be charged below freezing; if the bank lives in an unheated space, plan temperature management or low-temperature charging limits.

Installation and inspection

Battery banks need overcurrent protection, a disconnecting means, and ventilation/clearance per the manufacturer and Article 706 of the NEC. Document the commissioning: cell voltages, charge profile settings and the equipment list, so service calls later have a baseline.

Ordering

Send the load profile, system voltage and inverter model to the quote desk and we will confirm module count, interconnects and freight.
