Aesolar AE 595CMD-144BDS
PayPal Pay in 4 interest-free payments of $29.75 on qualifying orders, or monthly financing with PayPal Pay Later.
Available at checkout for eligible US buyers. Subject to approval.
Ships by freight. Carrier checkout rates can’t price this correctly — we quote the exact delivered rate to your ZIP.
Orders ship via freight or ground from our Louisville, KY warehouse. Tracking provided once your order ships.
Ships via LTL freight — palletized, liftgate available. Our team confirms freight details within 1 business day.
Secure checkout · Wire/ACH accepted on quotes · Freight arranged for you
Transit estimates from Louisville, KY. Freight details →
- SKU
- PES-SPS-SOL-0376
Complete the job
Compatible gear contractors pair with this item
PES Supply is an authorized distributor for ENF Solar. 50,000+ SKUs from 169 authorized brands.
Type Monocrystalline Model No. AE 595CMD-144BDS Product Warranty 15 Years Power Warranty 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +1.33 % Maximum Power (Pmax) 595 Wp Voltage at Maximum Power (Vmpp) 43.46 V Current at Maximum Power (Impp) 13.69 A Open Circuit Voltage (Voc) 52.21 V Short Circuit Current (Isc) 14.61 A Panel Efficiency 23.05 % Maximum Power (Pmax) 452 Wp Voltage at Maximum Power (Vmpp) 40.39 V Current at Maximum Power (Impp) 11.19 A Open Circuit Voltage (Voc) 48.8 V Short Circuit Current (Isc) 11.75 A Temperature 42±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.046 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2278x1133x30 mm Weight 31 kg Cell Size 182×91 mm Cell Number 144 Glass Type Anti-reflection Coating, Tempered Glass Thickness 2 mm Encapsulant Type POE Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 1200 mm Download Manufacturer's PDF Datasheet
Technology: Bifacial, TOPCon, N-type
Power Range: 570 ~ 595 Wp
Panel Efficiency: 22.08 ~ 23.05 %
Weight: 31 kg
Seller: AE Alternative Energy GmbH
Country: Germany
| SKU | PES-SPS-SOL-0376 |
|---|---|
| Manufacturer | ENF Solar |
| Container price | |
| Container qty | |
| Pallet price | |
| Pallet qty | |
| Unit price | |
| Manufacturer | |
| Model number |
No documents available for this product. Contact us to request documentation.
