Aesolar AE 620CMER-132BDS
PayPal Pay in 4 interest-free payments of $31.00 on qualifying orders, or monthly financing with PayPal Pay Later.
Available at checkout for eligible US buyers. Subject to approval.
Ships by freight. Carrier checkout rates can’t price this correctly — we quote the exact delivered rate to your ZIP.
Orders ship via freight or ground from our Louisville, KY warehouse. Tracking provided once your order ships.
Ships via LTL freight — palletized, liftgate available. Our team confirms freight details within 1 business day.
Secure checkout · Wire/ACH accepted on quotes · Freight arranged for you
Transit estimates from Louisville, KY. Freight details →
- SKU
- PES-SPS-SOL-0379
Complete the job
Compatible gear contractors pair with this item
PES Supply is an authorized distributor for ENF Solar. 50,000+ SKUs from 169 authorized brands.
Type Monocrystalline Model No. AE 620CMER-132BDS Product Warranty 15 Years Power Warranty 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 620 Wp Voltage at Maximum Power (Vmpp) 41.4 V Current at Maximum Power (Impp) 14.98 A Open Circuit Voltage (Voc) 49.6 V Short Circuit Current (Isc) 16.03 A Panel Efficiency 22.97 % Maximum Power (Pmax) 474 Wp Voltage at Maximum Power (Vmpp) 38.6 V Current at Maximum Power (Impp) 12.28 A Open Circuit Voltage (Voc) 47.1 V Short Circuit Current (Isc) 12.9 A Temperature 43±2 °C Operating Temperature Range -45 - +80 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.24 %/°C Temperature Coefficient of Isc 0.04 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 2382x1133x30 mm Weight 33.7 kg Cell Size 210×210 mm Cell Number 132 Glass Type Anti-reflection Coating, Tempered Glass Thickness 2 mm Encapsulant Type POE Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 350 mm Download Manufacturer's PDF Datasheet
Technology: TOPCon
Power Range: 610 ~ 630 Wp
Panel Efficiency: 22.6 ~ 23.34 %
Weight: 33.7 kg
Seller: AE Alternative Energy GmbH
Country: Germany
| SKU | PES-SPS-SOL-0379 |
|---|---|
| Manufacturer | ENF Solar |
| Container price | |
| Container qty | |
| Pallet price | |
| Pallet qty | |
| Unit price | |
| Manufacturer | |
| Model number |
No documents available for this product. Contact us to request documentation.
