• AESOLAR AE470ICMD-108BDE
1 1

Out of Stock

AESOLAR AE470ICMD-108BDE

AESOLAR AE470ICMD-108BDE

$94.00 USD
$94.00 USD
Sale Sold out
Shipping calculated at checkout.
Return policy

Specification

  • SKU:PES-SPS-SOL-0442
  • Container price: $50,760.00 USD
  • Container qty: 720
  • Pallet price: $2,397.00 USD
  • Pallet qty: 30
  • Unit price: $94.00 USD
View full details

Product Description

  • Type Monocrystalline Model No. AE470ICMD-108BDE Product Warranty 30 Years Power Warranty 30 Years of 88.85 % Total Degradation Rate ⏳ 0.37 % Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 470 Wp Voltage at Maximum Power (Vmpp) 33.29 V Current at Maximum Power (Impp) 14.13 A Open Circuit Voltage (Voc) 40.31 V Short Circuit Current (Isc) 14.78 A Panel Efficiency 23 % Maximum Power (Pmax) 357 Wp Voltage at Maximum Power (Vmpp) 31.6 V Current at Maximum Power (Impp) 11.3 A Open Circuit Voltage (Voc) 38.28 V Short Circuit Current (Isc) 11.84 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.26 %/°C Temperature Coefficient of Voc -0.20 %/°C Temperature Coefficient of Isc 0.05 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 1800x1134x30 mm Weight 23.5 kg Cell Size 210×210 mm Cell Number 108 Glass Type Anti-reflection Coating, Tempered Glass Thickness 2 mm Encapsulant Type POE Frame Type Anodized Aluminium, Black Junction Box Diodes 3 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 400 mm Download Manufacturer's PDF Datasheet

    Technology: Back Contact
    Power Range: 470 ~ 485 Wp
    Panel Efficiency: 23 ~ 23.8 %
    Weight: 23.5 kg
    Seller: AE Alternative Energy GmbH
    Country: Germany
