• AESOLAR AE540MD-144
1 1

Out of Stock

AESOLAR AE540MD-144

AESOLAR AE540MD-144

$28.80 USD
$28.80 USD
Sale Sold out
Shipping calculated at checkout.
Return policy

Specification

  • SKU:PES-SPS-SOL-0473
  • Container price: $15,552.00 USD
  • Container qty: 720
  • Pallet price: $734.40 USD
  • Pallet qty: 30
  • Unit price: $28.80 USD
View full details

Product Description

  • Type Monocrystalline Model No. AE540MD-144 Product Warranty 15 Years Power Warranty 30 Years of 81.55 % Total Degradation Rate ⏳ 0.62 % Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 540 Wp Voltage at Maximum Power (Vmpp) 42.15 V Current at Maximum Power (Impp) 12.81 A Open Circuit Voltage (Voc) 49.9 V Short Circuit Current (Isc) 13.57 A Panel Efficiency 20.92 % Maximum Power (Pmax) 407 Wp Voltage at Maximum Power (Vmpp) 39.7 V Current at Maximum Power (Impp) 10.25 A Open Circuit Voltage (Voc) 47.4 V Short Circuit Current (Isc) 10.86 A Temperature 45±2 °C Operating Temperature Range -40 - +85 °C Temperature Coefficient of Pmax -0.350 %/°C Temperature Coefficient of Voc -0.275 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2278x1133x35 mm Weight 27 kg Cell Number 144 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Encapsulant Type EVA Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 350 mm Download Manufacturer's PDF Datasheet

    Technology: PERC
    Power Range: 530 ~ 550 Wp
    Panel Efficiency: 20.53 ~ 21.31 %
    Weight: 27 kg
    Seller: AE Alternative Energy GmbH
    Country: Germany
