• G-STAR GSN7S54T-430BB
1 1

Out of Stock

G-STAR GSN7S54T-430BB

G-STAR GSN7S54T-430BB

$5.00 USD
$5.00 USD
Sale Sold out
Shipping calculated at checkout.
Return policy

Specification

  • SKU:PES-SPS-SOL-6063
  • Container price: $129.60 USD
  • Container qty: 720
  • Pallet price: $6.12 USD
  • Pallet qty: 30
  • Unit price: $0.24 USD
View full details

Product Description

  • Type Monocrystalline Model No. GSN7S54T-430BB Product Warranty 25 Years Power Warranty 1 Years of 99 %, 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 430 Wp Voltage at Maximum Power (Vmpp) 31.88 V Current at Maximum Power (Impp) 13.49 A Open Circuit Voltage (Voc) 38.49 V Short Circuit Current (Isc) 14.23 A Panel Efficiency 22.02 % Maximum Power (Pmax) 326 Wp Voltage at Maximum Power (Vmpp) 31.33 V Current at Maximum Power (Impp) 10.41 A Open Circuit Voltage (Voc) 38.2 V Short Circuit Current (Isc) 10.94 A Temperature 43±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.3 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.046 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 1722x1134x32 mm Weight 22 kg Cell Size 182×91 mm Cell Number 108 Glass Type Anti-reflection Coating Glass Thickness 3.2 mm Frame Type Anodized Aluminium, Black Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Length 300 mm Download Manufacturer's PDF Datasheet

    Technology: TOPCon, N-type
    Power Range: 420 ~ 440 Wp
    Panel Efficiency: 21.51 ~ 22.53 %
    Weight: 22 kg
    Seller: G-STAR Pte. Ltd.
    Country: Singapore
