Horay Solar HS450TC-MHC-D
Horay Solar HS450TC-MHC-D
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-8535
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. HS450TC-MHC-D Product Warranty 15 Years Power Warranty 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 450 Wp Voltage at Maximum Power (Vmpp) 29.95 V Current at Maximum Power (Impp) 15.02 A Open Circuit Voltage (Voc) 36.04 V Short Circuit Current (Isc) 15.87 A Panel Efficiency 22.5 % Maximum Power (Pmax) 343 Wp Voltage at Maximum Power (Vmpp) 27.89 V Current at Maximum Power (Impp) 12.29 A Open Circuit Voltage (Voc) 34.24 V Short Circuit Current (Isc) 12.81 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.28 %/°C Temperature Coefficient of Voc -0.23 %/°C Temperature Coefficient of Isc 0.04 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 1762x1134x30 mm Weight 24.5 kg Cell Number 96 Glass Type Anti-reflection Coating Glass Thickness 2 mm Frame Type Anodized Aluminium, Black Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 1100 mm Download Manufacturer's PDF Datasheet
Technology: Bifacial, N-type
Power Range: 435 ~ 455 Wp
Panel Efficiency: 21.8 ~ 22.8 %
Weight: 24.5 kg
Seller: Horay Solar Co., Ltd
Country: China -
