HY SOLAR 505

HY SOLAR 505

$5.00 USD
$5.00 USD
Sale Sold out
Shipping calculated at checkout.
Return policy

Specification

  • SKU:PES-SPS-SOL-7848
  • Container price: $64.80 USD
  • Container qty: 720
  • Pallet price: $3.06 USD
  • Pallet qty: 30
  • Unit price: $0.12 USD
View full details

Product Description

  • Type Monocrystalline Model No. 505 Product Warranty 15 Years Power Warranty 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 505 Wp Voltage at Maximum Power (Vmpp) 36.73 V Current at Maximum Power (Impp) 13.75 A Open Circuit Voltage (Voc) 43.92 V Short Circuit Current (Isc) 14.49 A Panel Efficiency 22.8 % Maximum Power (Pmax) 378.8 Wp Voltage at Maximum Power (Vmpp) 34.47 V Current at Maximum Power (Impp) 10.99 A Open Circuit Voltage (Voc) 41.39 V Short Circuit Current (Isc) 11.63 A Temperature 42±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.24 %/°C Temperature Coefficient of Isc 0.043 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 1952x1134x30 mm Weight 26.5 kg Cell Size 183.75×182.2 mm Cell Number 120 Glass Type Anti-reflection Coating Glass Thickness 2 mm Encapsulant Type EVA Frame Type Anodized Aluminium, Black Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Datasheet

    Technology: Bifacial, TOPCon, N-type
    Power Range: 495 ~ 515 Wp
    Panel Efficiency: 22.4 ~ 23.3 %
    Weight: 26.5 kg
    Seller: Hongyuan Green Energy Co., Ltd.
    Country: China
