HY SOLAR 705
HY SOLAR 705
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-7865
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. 705 Product Warranty 15 Years Power Warranty 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 705 Wp Voltage at Maximum Power (Vmpp) 40.27 V Current at Maximum Power (Impp) 17.51 A Open Circuit Voltage (Voc) 48.66 V Short Circuit Current (Isc) 18.34 A Panel Efficiency 22.7 % Maximum Power (Pmax) 534.8 Wp Voltage at Maximum Power (Vmpp) 37.93 V Current at Maximum Power (Impp) 14.1 A Open Circuit Voltage (Voc) 46.32 V Short Circuit Current (Isc) 14.76 A Temperature 42±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.24 %/°C Temperature Coefficient of Isc 0.043 %/°C Maximum System Voltage 1500 V Series Fuse Rating 35 A Panel Dimension (H/W/D) 2384x1303x33 mm Weight 38.3 kg Cell Size 210×210 mm Cell Number 132 Glass Type Anti-reflection Coating Glass Thickness 2 mm Encapsulant Type EVA Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Datasheet
Technology: Bifacial, TOPCon, N-type
Power Range: 705 ~ 725 Wp
Panel Efficiency: 22.7 ~ 23.3 %
Weight: 38.3 kg
Seller: Hongyuan Green Energy Co., Ltd.
Country: China -
