• MY Solar MY-M10/144-530
1 1

Out of Stock

MY Solar MY-M10/144-530

MY Solar MY-M10/144-530

$5.00 USD
$5.00 USD
Sale Sold out
Shipping calculated at checkout.
Return policy

Specification

  • SKU:PES-SPS-SOL-12104
  • Competitor price comparison: {"pes_price":0.1,"avg_competitor_price":5704.92,"min_competitor_price":5704.92,"max_competitor_price":5704.92,"diff_pct":5704820.0,"competitor_count":1,"checked_at":"2026-07-21"}
  • Container price: $54.00 USD
  • Container qty: 720
  • Pallet price: $2.55 USD
  • Pallet qty: 30
  • Unit price: $0.10 USD
View full details

Product Description

  • Type Monocrystalline Model No. MY-M10/144-530 Product Warranty 12 Years Power Warranty 12 Years of 90 %, 25 Years of 80.1 % Total Degradation Rate ⏳ 0.8 % Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 530 Wp Voltage at Maximum Power (Vmpp) 40.47 V Current at Maximum Power (Impp) 13.1 A Open Circuit Voltage (Voc) 49.02 V Short Circuit Current (Isc) 13.79 A Panel Efficiency 20.54 % Maximum Power (Pmax) 394.44 Wp Voltage at Maximum Power (Vmpp) 37.65 V Current at Maximum Power (Impp) 10.08 A Open Circuit Voltage (Voc) 46.27 V Short Circuit Current (Isc) 11.14 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.37 %/°C Temperature Coefficient of Voc -0.29 %/°C Temperature Coefficient of Isc 0.048 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2278x1133x35 mm Weight 28 kg Cell Size 182×91 mm Cell Number 144 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Encapsulant Type EVA Back Cover Type TPE Frame Type Anodized Aluminium Junction Box Diodes 2 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 350 mm Download Manufacturer's PDF Datasheet

    Technology: PERC
    Power Range: 530 ~ 560 Wp
    Panel Efficiency: 20.54 ~ 21.68 %
    Weight: 28 kg
    Seller: MY Solar Technology Co., Ltd.
    Country: China
