MY Solar MY-M3/96-520
MY Solar MY-M3/96-520
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-12189
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. MY-M3/96-520 Product Warranty 25 Years Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 520 Wp Voltage at Maximum Power (Vmpp) 49.9 V Current at Maximum Power (Impp) 10.42 A Open Circuit Voltage (Voc) 60.9 V Short Circuit Current (Isc) 10.83 A Panel Efficiency 19.9 % Maximum Power (Pmax) 385.1 Wp Voltage at Maximum Power (Vmpp) 46.3 V Current at Maximum Power (Impp) 8.32 A Open Circuit Voltage (Voc) 56.6 V Short Circuit Current (Isc) 8.95 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.37 %/°C Temperature Coefficient of Voc -0.29 %/°C Temperature Coefficient of Isc 0.048 %/°C Maximum System Voltage 1000 V Series Fuse Rating 10 A Panel Dimension (H/W/D) 1980x1320x40 mm Weight 30.3 kg Cell Size 158.75×158.75 mm Cell Number 96 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 67 Cable Crossection 4 mm2 Cable Length 900 mm Download M
Power Range: 500 ~ 520 Wp
Panel Efficiency: 19.1 ~ 19.9 %
Weight: 30.3 kg
Seller Name: MY Solar Technology Co., Ltd.
Country: China -
