MY Solar MY-M6/36-210
MY Solar MY-M6/36-210
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-12199
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. MY-M6/36-210 Product Warranty 25 Years Power Tolerance 0 ~ +2.5 % Maximum Power (Pmax) 210 Wp Voltage at Maximum Power (Vmpp) 21.78 V Current at Maximum Power (Impp) 9.64 A Open Circuit Voltage (Voc) 24.44 V Short Circuit Current (Isc) 10.88 A Panel Efficiency 19.09 % Maximum Power (Pmax) 156.83 Wp Voltage at Maximum Power (Vmpp) 20.26 V Current at Maximum Power (Impp) 7.73 A Open Circuit Voltage (Voc) 22.9 V Short Circuit Current (Isc) 8.79 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.39 %/°C Temperature Coefficient of Voc -0.3 %/°C Temperature Coefficient of Isc 0.06 %/°C Maximum System Voltage 1500 V Series Fuse Rating 20 A Panel Dimension (H/W/D) 1560x705x35 mm Weight 12.5 kg Cell Size 166×166 mm Cell Number 36 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Cable Crossection 4 mm2 Cable Length 300 mm Download Manu
Power Range: 195 ~ 215 Wp
Panel Efficiency: 17.73 ~ 19.55 %
Weight: 12.5 kg
Seller Name: MY Solar Technology Co., Ltd.
Country: China -
