    MY Solar MYP2036-150

    MY Solar MYP2036-150

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-12227
    • Container price: $91.80 USD
    • Container qty: 720
    • Pallet price: $4.33 USD
    • Pallet qty: 30
    • Unit price: $0.17 USD
    View full details

    Product Description

    • Type Polycrystalline Model No. MYP2036-150 Product Warranty 25 Years Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 150 Wp Voltage at Maximum Power (Vmpp) 18.2 V Current at Maximum Power (Impp) 8.24 A Open Circuit Voltage (Voc) 22.2 V Short Circuit Current (Isc) 8.71 A Panel Efficiency 15.1 % Maximum Power (Pmax) 111.1 Wp Voltage at Maximum Power (Vmpp) 16.9 V Current at Maximum Power (Impp) 6.58 A Open Circuit Voltage (Voc) 20.63 V Short Circuit Current (Isc) 7.08 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.37 %/°C Temperature Coefficient of Voc -0.29 %/°C Temperature Coefficient of Isc 0.048 %/°C Maximum System Voltage 600 V Series Fuse Rating 10 A Panel Dimension (H/W/D) 1480x670x35 mm Weight 11.2 kg Cell Size 156.75×156.75 mm Cell Number 36 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 67 Cable Crossection 4 mm2 Cable Length 650 mm Download Manuf

      Power Range: 150 ~ 170 Wp
      Panel Efficiency: 15.1 ~ 17.1 %
      Weight: 11.2 kg
      Seller Name: MY Solar Technology Co., Ltd.
      Country: China
