MY Solar MYP2036-165
MY Solar MYP2036-165
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-12230
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Polycrystalline Model No. MYP2036-165 Product Warranty 25 Years Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 165 Wp Voltage at Maximum Power (Vmpp) 18.8 V Current at Maximum Power (Impp) 8.78 A Open Circuit Voltage (Voc) 22.9 V Short Circuit Current (Isc) 9.28 A Panel Efficiency 16.6 % Maximum Power (Pmax) 122.2 Wp Voltage at Maximum Power (Vmpp) 17.4 V Current at Maximum Power (Impp) 7.01 A Open Circuit Voltage (Voc) 21.3 V Short Circuit Current (Isc) 7.54 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.37 %/°C Temperature Coefficient of Voc -0.29 %/°C Temperature Coefficient of Isc 0.048 %/°C Maximum System Voltage 600 V Series Fuse Rating 10 A Panel Dimension (H/W/D) 1480x670x35 mm Weight 11.2 kg Cell Size 156.75×156.75 mm Cell Number 36 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 67 Cable Crossection 4 mm2 Cable Length 650 mm Download Manufa
Power Range: 150 ~ 170 Wp
Panel Efficiency: 15.1 ~ 17.1 %
Weight: 11.2 kg
Seller Name: MY Solar Technology Co., Ltd.
Country: China -
