MY Solar MYP3036-165
MY Solar MYP3036-165
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-12233
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Polycrystalline Model No. MYP3036-165 Product Warranty 25 Years Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 165 Wp Voltage at Maximum Power (Vmpp) 18.7 V Current at Maximum Power (Impp) 8.82 A Open Circuit Voltage (Voc) 22.8 V Short Circuit Current (Isc) 9.33 A Panel Efficiency 16.18 % Maximum Power (Pmax) 122.2 Wp Voltage at Maximum Power (Vmpp) 17.3 V Current at Maximum Power (Impp) 7.04 A Open Circuit Voltage (Voc) 21.2 V Short Circuit Current (Isc) 7.58 A Temperature 45±2 °C Operating Temperature Range -420 - 85 °C Temperature Coefficient of Pmax -0.37 %/°C Temperature Coefficient of Voc -0.29 %/°C Temperature Coefficient of Isc 0.048 %/°C Maximum System Voltage 1000 V Series Fuse Rating 2 A Panel Dimension (H/W/D) 1500x680x35 mm Weight 11.3 kg Cell Size 158.75×158.75 mm Cell Number 36 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 67 Cable Crossection 4 mm2 Cable Length 900 mm Download Manu
Power Range: 160 ~ 180 Wp
Panel Efficiency: 15.69 ~ 17.65 %
Weight: 11.3 kg
Seller Name: MY Solar Technology Co., Ltd.
Country: China -
