PolyCrown Solar Tech NS-480MH-120
PayPal Pay in 4 interest-free payments of $42.00 on qualifying orders, or monthly financing with PayPal Pay Later.
Available at checkout for eligible US buyers. Subject to approval.
Ships by freight. Carrier checkout rates can’t price this correctly — we quote the exact delivered rate to your ZIP.
Orders ship via freight or ground from our Louisville, KY warehouse. Tracking provided once your order ships.
Ships via LTL freight — palletized, liftgate available. Our team confirms freight details within 1 business day.
Secure checkout · Wire/ACH accepted on quotes · Freight arranged for you
Transit estimates from Louisville, KY. Freight details →
- SKU
- PES-SPS-SOL-14378
Complete the job
Compatible gear contractors pair with this item
PES Supply is an authorized distributor for ENF Solar. 50,000+ SKUs from 169 authorized brands.
Type Monocrystalline Model No. NS-480MH-120 Product Warranty 15 Years Power Warranty 15 Years of 93 %, 25 Years of 89 % Total Degradation Rate ⏳ 0.44 % Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 480 Wp Voltage at Maximum Power (Vmpp) 35.62 V Current at Maximum Power (Impp) 13.48 A Open Circuit Voltage (Voc) 42.63 V Short Circuit Current (Isc) 14.43 A Panel Efficiency 22.19 % Maximum Power (Pmax) 363 Wp Voltage at Maximum Power (Vmpp) 33.56 V Current at Maximum Power (Impp) 10.81 A Open Circuit Voltage (Voc) 40.35 V Short Circuit Current (Isc) 11.76 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 1907x1134x30 mm Weight 21.5 kg Cell Number 120 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Encapsulant Type EVA Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Datasheet
Technology: PERC, TOPCon, HJT, N-type
Power Range: 450 ~ 485 Wp
Panel Efficiency: 20.8 ~ 22.42 %
Weight: 21.5 kg
Seller: PolyCrown Solar Tech
Country: China
| SKU | PES-SPS-SOL-14378 |
|---|---|
| Manufacturer | ENF Solar |
| Container price | |
| Container qty | |
| Pallet price | |
| Pallet qty | |
| Unit price | |
| Cell type | |
| Manufacturer | |
| Model number |
No documents available for this product. Contact us to request documentation.
