PolyCrown Solar Tech NS-485MH-120
PolyCrown Solar Tech NS-485MH-120
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-14379
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. NS-485MH-120 Product Warranty 15 Years Power Warranty 15 Years of 93 %, 25 Years of 89 % Total Degradation Rate ⏳ 0.44 % Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 485 Wp Voltage at Maximum Power (Vmpp) 35.82 V Current at Maximum Power (Impp) 13.54 A Open Circuit Voltage (Voc) 42.83 V Short Circuit Current (Isc) 14.51 A Panel Efficiency 22.42 % Maximum Power (Pmax) 367 Wp Voltage at Maximum Power (Vmpp) 33.75 V Current at Maximum Power (Impp) 10.86 A Open Circuit Voltage (Voc) 40.53 V Short Circuit Current (Isc) 11.82 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 1907x1134x30 mm Weight 21.5 kg Cell Number 120 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Encapsulant Type EVA Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Datasheet
Technology: PERC, TOPCon, HJT, N-type
Power Range: 450 ~ 485 Wp
Panel Efficiency: 20.8 ~ 22.42 %
Weight: 21.5 kg
Seller: PolyCrown Solar Tech
Country: China -
