Out of Stock
PolyCrown Solar Tech NS-565MH-144
PolyCrown Solar Tech NS-565MH-144
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-14386
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. NS-565MH-144 Product Warranty 15 Years Power Warranty 15 Years of 93 %, 30 Years of 87 % Total Degradation Rate ⏳ 0.43 % Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 565 Wp Voltage at Maximum Power (Vmpp) 42.56 V Current at Maximum Power (Impp) 13.28 A Open Circuit Voltage (Voc) 50.7 V Short Circuit Current (Isc) 14.28 A Panel Efficiency 21.86 % Maximum Power (Pmax) 427 Wp Voltage at Maximum Power (Vmpp) 40.1 V Current at Maximum Power (Impp) 10.65 A Open Circuit Voltage (Voc) 47.98 V Short Circuit Current (Isc) 11.64 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 2279x1134x30 mm Weight 32 kg Cell Size 182×91 mm Cell Number 144 Glass Type Anti-reflection Coating, Tempered Glass Thickness 2 mm Frame Type Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Datasheet
Technology: Bifacial, TOPCon, HJT, N-type
Power Range: 565 ~ 585 Wp
Panel Efficiency: 21.86 ~ 22.63 %
Weight: 32 kg
Seller: PolyCrown Solar Tech
Country: China -
