PolyCrown Solar Tech NS-710MH-132
PolyCrown Solar Tech NS-710MH-132
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-14407
- Container price:
- Container qty:
- Odoo id:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. NS-710MH-132 Product Warranty 15 Years Power Warranty 15 Years of 93 %, 25 Years of 89 % Total Degradation Rate ⏳ 0.44 % Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 710 Wp Voltage at Maximum Power (Vmpp) 41.59 V Current at Maximum Power (Impp) 17.08 A Open Circuit Voltage (Voc) 49.84 V Short Circuit Current (Isc) 17.81 A Panel Efficiency 22.85 % Maximum Power (Pmax) 537 Wp Voltage at Maximum Power (Vmpp) 39.19 V Current at Maximum Power (Impp) 13.7 A Open Circuit Voltage (Voc) 47.17 V Short Circuit Current (Isc) 14.51 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 2384x1303x30 mm Weight 34 kg Cell Number 132 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Encapsulant Type EVA Frame Type Aluminium Junction Box Diodes
Technology: PERC, TOPCon, HJT, N-type
Power Range: 690 ~ 730 Wp
Panel Efficiency: 22.21 ~ 23.5 %
Weight: 34 kg
Seller Name: PolyCrown Solar Tech
Country: China -
