PolyCrown Solar Tech NS-730MH-132
PolyCrown Solar Tech NS-730MH-132
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-14409
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. NS-730MH-132 Product Warranty 15 Years Power Warranty 15 Years of 93 %, 30 Years of 87 % Total Degradation Rate ⏳ 0.43 % Power Tolerance 0 ~ +5 % Maximum Power (Pmax) 730 Wp Voltage at Maximum Power (Vmpp) 42.19 V Current at Maximum Power (Impp) 17.31 A Open Circuit Voltage (Voc) 50.16 V Short Circuit Current (Isc) 18.19 A Panel Efficiency 23.5 % Maximum Power (Pmax) 552 Wp Voltage at Maximum Power (Vmpp) 39.75 V Current at Maximum Power (Impp) 13.89 A Open Circuit Voltage (Voc) 47.47 V Short Circuit Current (Isc) 14.82 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 2384x1303x30 mm Weight 38.7 kg Cell Size 210×105 mm Cell Number 132 Glass Type Anti-reflection Coating, Tempered Glass Thickness 2.0 mm Encapsulant Type EVA Frame Type Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Datasheet
Technology: Bifacial, TOPCon, HJT, N-type
Power Range: 700 ~ 730 Wp
Panel Efficiency: 22.53 ~ 23.5 %
Weight: 38.7 kg
Seller: PolyCrown Solar Tech
Country: China -
