Out of Stock
Q-SUN Solar QNHT-2 605
Q-SUN Solar QNHT-2 605
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-14799
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. QNHT-2 605 Product Warranty 15 Years Maximum Power (Pmax) 605 Wp Voltage at Maximum Power (Vmpp) 40.01 V Current at Maximum Power (Impp) 15.12 A Open Circuit Voltage (Voc) 47.65 V Short Circuit Current (Isc) 16.07 A Panel Efficiency 22.4 % Maximum Power (Pmax) 457 Wp Voltage at Maximum Power (Vmpp) 37.81 V Current at Maximum Power (Impp) 12.1 A Open Circuit Voltage (Voc) 45.27 V Short Circuit Current (Isc) 12.86 A Temperature 43±2 °C Operating Temperature Range -45 - +85 °C Temperature Coefficient of Pmax -0.380 %/°C Temperature Coefficient of Voc -0.289 %/°C Temperature Coefficient of Isc +0.055 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 2382x1134x35 mm Weight 32.8 kg Cell Size 210×210 mm Cell Number 132 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Encapsulant Type EVA Back Cover Type PET Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type M
Technology: TOPCon
Power Range: 600 ~ 620 Wp
Panel Efficiency: 22.2 ~ 23 %
Weight: 32.8 kg
Seller Name: Q-SUN Anhui Co., Ltd
Country: China -
