Q-SUN Solar QNHT-2 620
Q-SUN Solar QNHT-2 620
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-14802
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. QNHT-2 620 Product Warranty 15 Years Maximum Power (Pmax) 620 Wp Voltage at Maximum Power (Vmpp) 40.6 V Current at Maximum Power (Impp) 15.27 A Open Circuit Voltage (Voc) 48.32 V Short Circuit Current (Isc) 16.24 A Panel Efficiency 23 % Maximum Power (Pmax) 469 Wp Voltage at Maximum Power (Vmpp) 38.37 V Current at Maximum Power (Impp) 12.22 A Open Circuit Voltage (Voc) 45.9 V Short Circuit Current (Isc) 12.99 A Temperature 43±2 °C Operating Temperature Range -45 - +85 °C Temperature Coefficient of Pmax -0.380 %/°C Temperature Coefficient of Voc -0.289 %/°C Temperature Coefficient of Isc +0.055 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 2382x1134x35 mm Weight 32.8 kg Cell Size 210×210 mm Cell Number 132 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Encapsulant Type EVA Back Cover Type PET Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4
Technology: TOPCon
Power Range: 600 ~ 620 Wp
Panel Efficiency: 22.2 ~ 23 %
Weight: 32.8 kg
Seller Name: Q-SUN Anhui Co., Ltd
Country: China -
