    Runtech China RT390WM

    Runtech China RT390WM

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-16261
    • Container price: $48.60 USD
    • Container qty: 720
    • Pallet price: $2.29 USD
    • Pallet qty: 30
    • Unit price: $0.09 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. RT390WM Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 390 Wp Voltage at Maximum Power (Vmpp) 30.64 V Current at Maximum Power (Impp) 12.73 A Open Circuit Voltage (Voc) 36.85 V Short Circuit Current (Isc) 13.61 A Panel Efficiency 20 % Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.350 %/°C Temperature Coefficient of Voc -0.275 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 1722x1134x30 mm Weight 20.5 kg Cell Number 108 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Datasheet

      Technology: PERC, TOPCon, N-type
      Power Range: 390 ~ 420 Wp
      Panel Efficiency: 20 ~ 21.6 %
      Weight: 20.5 kg
      Seller Name: Runtech China Co.,Ltd
      Country: China
