    Shinson Technology S335M60P1B

    Shinson Technology S335M60P1B

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-17203
    • Container price: $91.80 USD
    • Container qty: 720
    • Pallet price: $4.33 USD
    • Pallet qty: 30
    • Unit price: $0.17 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. S335M60P1B Product Warranty 25 Years Power Tolerance 0 ~ +1.5 % Maximum Power (Pmax) 335 Wp Voltage at Maximum Power (Vmpp) 34.4 V Current at Maximum Power (Impp) 9.51 A Open Circuit Voltage (Voc) 40.8 V Short Circuit Current (Isc) 10.02 A Panel Efficiency 19.78 % Maximum Power (Pmax) 253 Wp Voltage at Maximum Power (Vmpp) 31.9 V Current at Maximum Power (Impp) 8.03 A Open Circuit Voltage (Voc) 38.7 V Short Circuit Current (Isc) 8.5 A Temperature 43±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.34 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.05 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 1686x998x28 mm Weight 17.8 kg Cell Size 158.75×79.4 mm Cell Number 120 Glass Type Tempered Glass Thickness 3.2 mm Encapsulant Type EVA Frame Type Anodized Aluminium, Black Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 1

      Technology: PERC
      Power Range: 330 ~ 345 Wp
      Panel Efficiency: 19.5 ~ 20.68 %
      Weight: 17.8 kg
      Seller Name: Shinson Technology Co., Ltd.
      Country: China
