Type Monocrystalline Model No. S340M60P1B Product Warranty 25 Years Power Tolerance 0 ~ +1.5 % Maximum Power (Pmax) 340 Wp Voltage at Maximum Power (Vmpp) 34.6 V Current at Maximum Power (Impp) 9.6 A Open Circuit Voltage (Voc) 41 V Short Circuit Current (Isc) 10.11 A Panel Efficiency 20.56 % Maximum Power (Pmax) 256 Wp Voltage at Maximum Power (Vmpp) 31.9 V Current at Maximum Power (Impp) 8.17 A Open Circuit Voltage (Voc) 38.8 V Short Circuit Current (Isc) 8.62 A Temperature 43±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.34 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.05 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 1686x998x28 mm Weight 17.8 kg Cell Size 158.75×79.4 mm Cell Number 120 Glass Type Tempered Glass Thickness 3.2 mm Encapsulant Type EVA Frame Type Anodized Aluminium, Black Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 100
Technology: PERC
Power Range: 330 ~ 345 Wp
Panel Efficiency: 19.5 ~ 20.68 %
Weight: 17.8 kg
Seller Name: Shinson Technology Co., Ltd.
Country: China
