    Shinson Technology S405M54P3BFB

    Shinson Technology S405M54P3BFB

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-17227
    • Container price: $48.60 USD
    • Container qty: 720
    • Pallet price: $2.29 USD
    • Pallet qty: 30
    • Unit price: $0.09 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. S405M54P3BFB Product Warranty 30 Years Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 405 Wp Voltage at Maximum Power (Vmpp) 30.93 V Current at Maximum Power (Impp) 13.1 A Open Circuit Voltage (Voc) 37.22 V Short Circuit Current (Isc) 13.7 A Panel Efficiency 20.74 % Maximum Power (Pmax) 304 Wp Voltage at Maximum Power (Vmpp) 28.91 V Current at Maximum Power (Impp) 10.51 A Open Circuit Voltage (Voc) 34.73 V Short Circuit Current (Isc) 11.07 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.34 %/°C Temperature Coefficient of Voc -0.26 %/°C Temperature Coefficient of Isc 0.05 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 1722x1134x28 mm Weight 19.5 kg Cell Number 108 Glass Type Anti-reflection Coating Glass Thickness 2 mm Frame Type Anodized Aluminium, Black Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 1100

      Technology: Bifacial, PERC
      Power Range: 400 ~ 415 Wp
      Panel Efficiency: 20.48 ~ 21.25 %
      Weight: 19.5 kg
      Seller Name: Shinson Technology Co., Ltd.
      Country: China
